ABB SDCS-FEX-32B 3ADT220090R0037 DC Speed Regulator Excitation Module

Company Information
E-mail		[email protected]
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The ABB SDCS-FEX-32B (Part Number: 3ADT220090R0037) is a high-performance excitation module engineered for advanced DC motor control. Part of the ABB DCS500 and DCS600 family, this module plays a crucial role in providing closed-loop regulation of field excitation current — the core factor in controlling the torque and speed of DC motors.

This module is designed to interface directly with ABB’s drive systems, offering precise control, fast response times, and enhanced protection mechanisms. It ensures that excitation current is dynamically adjusted based on system feedback, delivering stable motor operation even under changing load conditions. Its compact modular design allows seamless integration and quick maintenance, making it ideal for high-demand industrial applications.

---

Technical Specifications

---

Applications

The ABB SDCS-FEX-32B 3ADT220090R0037 module is purpose-built for industries reliant on high-precision DC motor control. Its robust design and accurate field regulation make it ideal for:

• Steel & Metal Processing: Ensuring consistent motor torque during rolling, coiling, and cutting operations.

• Pulp & Paper Industry: Controlling speed in continuous production environments.

• Marine & Shipbuilding: Stabilizing propulsion systems and onboard cranes.

• Cement & Mining: Handling dynamic loads in crushers, conveyors, and kilns.

• Elevators & Hoisting Systems: Enabling field weakening and smooth motion transitions.

• Power Generation: Supporting excitation needs of synchronous generators and turbines.

This module is especially suitable for applications where smooth torque transitions, fast response, and thermal reliability are essential.

---

Product Advantages

• High-Speed Closed-Loop Regulation: Guarantees stable motor performance across varying loads.

• Excellent System Integration: Fully compatible with ABB’s DCS500/DCS600 drives.

• Built-In Protection: Prevents damage through overvoltage, field loss, and overcurrent safeguards.

• Low Maintenance: Modular design allows rapid replacement and reduced system downtime.

• Real-Time Diagnostics: Onboard fault monitoring ensures immediate feedback and prevention.

• Compact & Lightweight: Saves space in control cabinets and reduces system weight.

• Field Weakening Support: Enables higher RPM without loss of control or efficiency.

• Improved Efficiency: Minimizes unnecessary excitation current, improving energy use.

• Industrial Durability: Operates reliably in extreme conditions, from mining to marine.

• Globally Certified: Meets CE, RoHS, and EMC standards for international industrial use.

---

Frequently Asked Questions (FAQ)

1. What is the primary function of the SDCS-FEX-32B 3ADT220090R0037?
To regulate the field (excitation) current of DC motors in ABB DCS drive systems.

2. Which ABB drives is it compatible with?
It is compatible with DCS500 and DCS600 series drives.

3. How is the excitation current controlled?
Using closed-loop feedback, ensuring real-time adjustments to motor demands.

4. Does this module support dynamic braking?
Yes, it supports field current regulation even during regenerative braking.

5. Is it hot-swappable?
While modular, the system should be powered down during replacement to ensure safety.

6. What protection features are included?
The module includes overvoltage, overcurrent, thermal shutdown, and field loss protection.

7. Can it operate in humid environments?
Yes, it handles 5% to 95% non-condensing humidity, making it suitable for demanding environments.

8. How is it mounted within the system?
It is a plug-in board that fits directly into ABB drive enclosures.

9. What is its expected response time?
Typically under 1 millisecond, allowing fast control of field current.

10. How heavy is the module?
It weighs 0.2 kg, suitable for lightweight control cabinets.

---
