Product Introduction

---

The ABB SDCS-MP-1 (3BSE005635R0001) is a versatile power supply and control module used within ABB’s DC drive system, particularly in the DCS 400 and DCS 500 series. It functions as the main processing unit in the converter system, handling internal control logic, data communication, and system diagnostics. Integrated with robust signal processing capabilities, the SDCS-MP-1 ensures the reliable performance and control of direct current motors across a variety of industrial environments.

Designed with ABB’s emphasis on durability and industrial performance, the SDCS-MP-1 offers a dependable foundation for heavy-duty drive operations, from steel mills to chemical plants.

---

Product Advantages

---

• High Compatibility: Fully compatible with ABB DCS400 and DCS500 drives, ensuring seamless integration.

• Stable Performance: Delivers stable and efficient processing of drive control signals, minimizing operational interruptions.

• Modular Design: Facilitates easy maintenance and replacement, reducing overall system downtime.

• Industrial Grade Reliability: Designed for long life in industrial applications, including high temperatures and electrical noise environments.

• Efficient Communication: Supports fast data exchange with other modules via fiber optic links and serial communication ports.

• Extended Diagnostic Capabilities: Includes built-in diagnostics for system status, fault tracking, and performance monitoring.

---

Technical Specifications

---

---

Product Applications

---

• Metallurgical Industry: Control of DC motors in rolling mills and metal processing lines.

• Pulp and Paper: Ensures precise torque and speed control in paper machines.

• Oil & Gas: Used in pump drives and drilling control systems.

• Chemical Processing: Reliable speed control in mixers and chemical feed systems.

• Marine Industry: DC propulsion and winch systems.

• General Manufacturing: For all motor-driven processes requiring precision control and system monitoring.

---

Installation Instructions

---

1. Power Down the System: Ensure all power sources to the converter are disconnected before installation.

2. Access the Drive Cabinet: Open the ABB DCS drive unit and locate the control board slot.

3. Insert the SDCS-MP-1: Slide the module carefully into the designated position, ensuring alignment with the guide rails.

4. Secure the Module: Use screws or latching clips as applicable to secure the module firmly.

5. Connect Fiber and Communication Cables: Attach any fiber optic or serial communication cables according to ABB connection diagrams.

6. Run Initial Diagnostic Check: Once powered, monitor the diagnostic LEDs and verify module recognition via the drive software.

---

Frequently Asked Questions (FAQ)

---

Q1: What does the SDCS-MP-1 module control in the ABB DCS drive?
A1: It serves as the main processor that handles logic, control algorithms, and communication with peripheral modules.

Q2: Can I use SDCS-MP-1 in DCS600 systems?
A2: No, the SDCS-MP-1 is designed specifically for the DCS400 and DCS500 series.

Q3: How do I know if the SDCS-MP-1 module is faulty?
A3: Diagnostic LEDs on the module indicate fault conditions. Additionally, error codes will appear on the drive interface.

Q4: Is firmware upgrade possible on this module?
A4: No, this module does not support field firmware updates and must be replaced if a firmware revision is required.

Q5: Does the module require external power supply?
A5: No, the module is powered internally by the drive’s control power.

Q6: How do I clean the module if it’s dusty?
A6: Use dry compressed air or a soft brush. Avoid using liquids or solvents.

Q7: Is the SDCS-MP-1 hot-swappable?
A7: No, always power down the system before removing or installing the module.

Q8: What type of cable should be used for the fiber optic connection?
A8: Use ABB-specified industrial-grade fiber cables with compatible connectors.

Q9: Can I use the SDCS-MP-1 in outdoor applications?
A9: No, it’s designed for enclosed environments within control cabinets.

Q10: How long is the typical lifespan of the SDCS-MP-1?
A10: Under standard conditions, it can operate reliably for over 5 years.

---

Recommended Related Models (Same Series or Function)

---

1. SDCS-CON-2 – Control board for DCS500 drives

2. SDCS-POW-1 – Power supply module for DCS500 systems

3. SDCS-IOB-1 – Input/output board for signal interface

4. SDCS-FEX-1 – Field exciter interface board

5. SDCS-IOE-1 – Digital and analog expansion I/O module

6. SDCS-DSL-4 – Drive system logic module for DCS drives

---
