Product Introduction
The ABB SM812K01 3BSE072270R1 is a high-performance signal conditioning module designed for industrial automation and control systems. It is part of ABB’s Advant Controller 800M series, which is widely used in process control, power generation, and manufacturing industries. This module ensures reliable signal conversion, isolation, and distribution, enhancing system stability and accuracy.
Its robust construction and compatibility with various field devices make it suitable for harsh industrial environments. The module supports multiple input/output configurations, ensuring seamless integration into complex control systems.
Product Specifications
| Parameter | Value |
|---|---|
| Model Number | SM812K01 3BSE072270R1 |
| Product Type | Signal Conditioning Module |
| Input Channels | 8 (configurable) |
| Output Channels | 8 (configurable) |
| Input Signal Range | 0-20 mA, 4-20 mA, ±10 V, etc. |
| Output Signal Range | 0-20 mA, 4-20 mA, ±10 V, etc. |
| Isolation Voltage | 1500 V DC |
| Accuracy | ±0.1% of full scale |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Power Supply | 24 V DC (±10%) |
| Power Consumption | 2.5 W (typical) |
| Dimensions | 127.5 × 186× 59 mm |
| Weight | 0.63 kg |
| Mounting | DIN rail or panel mounting |
| Certifications | CE, UL, IEC standards |
Product Applications
The ABB SM812K01 3BSE072270R1 is widely used in industries requiring precise signal conditioning and isolation, including:
-
Process Control Systems – Ensures accurate signal transmission in chemical, oil & gas, and refinery applications.
-
Power Generation – Used in turbine control, boiler management, and grid monitoring systems.
-
Manufacturing Automation – Facilitates reliable signal conversion in PLC and DCS environments.
-
Water & Wastewater Treatment – Supports monitoring and control of pumps, valves, and sensors.
-
HVAC Systems – Enhances signal integrity in building automation.
Product Advantages
-
High Accuracy – Provides precise signal conversion with minimal deviation (±0.1%).
-
Robust Isolation – 1500 V DC isolation protects against electrical noise and surges.
-
Flexible Configuration – Supports multiple input/output signal types (mA, V, etc.).
-
Compact & Durable – DIN rail mounting saves space, suitable for harsh environments.
-
Wide Compatibility – Integrates seamlessly with ABB’s Advant Controller 800M and other systems.
-
Low Power Consumption – Energy-efficient design reduces operational costs.
-
Certified Safety – Complies with CE, UL, and IEC standards for industrial use.
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the SM812K01 module?
A1: It provides signal conditioning, isolation, and conversion for industrial control systems.
Q2: Can this module handle both current and voltage signals?
A2: Yes, it supports 0-20 mA, 4-20 mA, ±10 V, and other standard signals.
Q3: What is the isolation voltage rating?
A3: 1500 V DC, ensuring protection against electrical interference.
Q4: Is the module compatible with non-ABB systems?
A4: Yes, it can work with third-party PLCs and DCS systems with proper configuration.
Q5: What is the operating temperature range?
A5: -20°C to +70°C, suitable for most industrial environments.
Q6: How many input/output channels does it have?
A6: 8 configurable input and 8 output channels.
Q7: Does it require external power?
A7: Yes, it operates on 24 V DC (±10%).
Q8: Can it be mounted on a standard DIN rail?
A8: Yes, it supports DIN rail or panel mounting.
Q9: What certifications does it have?
A9: CE, UL, and IEC standards compliance.
Q10: How long is the warranty period?
A10: The standard warranty is 1 years.
Recommended Related Models
| Model Number | Description |
|---|---|
| SM811K01 3BSE072269R1 | 8-channel signal conditioning module |
| SM813K01 3BSE072271R1 | 16-channel signal conditioning module |
| SA801F 3BSE020510R1 | Analog input module for Advant 800M |
| SA802F 3BSE020511R1 | Analog output module for Advant 800M |
| SD812 3BSE008514R1 | Digital input module |
| SD822 3BSE008516R1 | Digital output module |
