Product Introduction
The ABB SS832 3BSC610068R1 is a high-performance signal splitter designed for industrial automation and process control systems. It ensures reliable signal distribution in demanding environments, maintaining accuracy and stability in measurement and control applications. This device is part of ABB’s renowned Signal Conditioning product line, known for its robustness and precision.
The SS832 is widely used in industries such as oil & gas, power generation, chemical processing, and water treatment, where signal integrity is critical. Its compact design, high immunity to electrical noise, and flexible configuration options make it a preferred choice for engineers and system integrators.
Product Specifications
| Parameter | Value |
|---|---|
| Model Number | SS832 3BSC610068R1 |
| Input Type | Analog (4-20 mA, 0-10 V, etc.) |
| Output Type | Isolated duplicated signals |
| Power Supply | 24 V DC (±10%) |
| Operating Temp. | -20°C to +60°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Isolation Voltage | 1500 V AC (input to output) |
| Accuracy | ±0.1% of full scale |
| Response Time | < 50 ms |
| Dimensions (WxHxD) | 22.5 x 100 x 115 mm |
| Weight | Approx. 250 g |
| Mounting | DIN rail |
| Certifications | CE, ATEX (if applicable) |
Applications
The ABB SS832 3BSC610068R1 is used in various industrial scenarios where signal splitting and conditioning are required:
-
Process Control Systems: Ensures accurate signal distribution for sensors and transmitters.
-
Power Plants: Reliable signal duplication for monitoring critical parameters.
-
Oil & Gas: Safe signal handling in hazardous environments.
-
Water/Wastewater Treatment: Maintains signal integrity in corrosive conditions.
-
Manufacturing Automation: Supports PLC and DCS systems with isolated outputs.
Product Advantages
-
High Precision: ±0.1% accuracy ensures reliable signal transmission.
-
Robust Isolation: 1500 V AC isolation prevents ground loops and noise interference.
-
Compact & Durable: DIN rail mounting saves space in control cabinets.
-
Wide Compatibility: Works with multiple input/output signal types.
-
Low Maintenance: Solid-state design ensures long-term reliability.
-
Compliance with Standards: Meets CE and ATEX (if applicable) for industrial safety.
Frequently Asked Questions (FAQ)
1. What is the primary function of the SS832 3BSC610068R1?
It is a signal splitter that takes one input signal and provides two or more isolated output signals.
2. Can it handle both current (4-20 mA) and voltage (0-10 V) signals?
Yes, it supports multiple analog signal types, depending on configuration.
3. What is the isolation voltage between input and output?
1500 V AC, ensuring protection against electrical noise and ground loops.
4. Is this device suitable for hazardous areas?
If certified (e.g., ATEX), it can be used in explosive atmospheres.
5. How is the SS832 powered?
It requires a 24 V DC power supply (±10% tolerance).
6. What is the response time of the signal splitter?
Less than 50 ms, ensuring real-time signal processing.
7. Can it be mounted on a standard DIN rail?
Yes, it is designed for DIN rail mounting (35 mm).
8. What is the operating temperature range?
It functions reliably between -20°C to +60°C.
9. Does it require calibration?
Factory-calibrated, but periodic checks are recommended for critical applications.
10. Is the module certified for industrial compliance?
Yes, it meets CE, UL, CSA, and RoHS standar
