Product Introduction
The ABB TA564-11 1TNE968901R3104 is a high-performance auxiliary contact block designed specifically for integration with ABB’s industrial control systems, particularly in motor starters, contactors, and automation modules. It is built for robust signal feedback, auxiliary circuit expansion, and enhancing operational safety in both low-voltage and medium-voltage systems.
Engineered with precision, the TA564-11 offers exceptional reliability and is commonly mounted onto contactors from the AF and A series. It features a modular snap-on design, enabling seamless installation and disassembly without the need for additional tools. Its compact structure also makes it suitable for installations where space constraints are a concern.
Product Features and Advantages
-
Reliable Signaling: Provides accurate indication and signaling of contactor status for enhanced system monitoring.
-
Flexible Mounting: Can be front- or side-mounted on compatible contactors, adding to its versatility.
-
High Mechanical Durability: Withstands a large number of mechanical operations, ensuring long-term service.
-
Compact Design: Slim profile allows efficient use of cabinet space.
-
Safe Operation: Supports electrical isolation, reducing the risk of faults or short circuits in auxiliary circuits.
-
Environmentally Resistant: Performs reliably in industrial environments subject to vibration, temperature fluctuations, and dust.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Code | TA564-11 1TNE968901R3104 |
| Function | Auxiliary Contact Block |
| Contact Configuration | 1 Normally Open (NO) + 1 Normally Closed (NC) |
| Rated Operational Voltage | 690 V AC / 600 V AC |
| Rated Current | 10 A |
| Insulation Voltage | 690 V |
| Mechanical Durability | >10 million operations |
| Electrical Durability | >0.3 million operations |
| Mounting Position | Front mount on A-series or AF-series contactors |
| Operating Temperature | -25°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Degree of Protection | IP20 |
| Dimensions | 40 x 250 x 150 mm |
| Weight | 0.036 kg |
| Standards Compliance | IEC 60947-5-1 |
Product Applications
The ABB TA564-11 auxiliary contact block is widely used in:
-
Motor starter combinations
-
Industrial control panels
-
Machine automation systems
-
Conveyor systems
-
HVAC and pump control setups
-
Power distribution systems
-
Process industries requiring contact status feedback
Installation Instructions
-
Ensure Safety: Before installation, disconnect all power to the equipment.
-
Mounting: Align the TA564-11 with the designated slot on the front side of an ABB A-series or AF-series contactor.
-
Snap-On Fit: Press the block firmly until it clicks into position. No tools are required.
-
Wiring: Connect the auxiliary terminals according to the control circuit diagram. Use appropriate wire gauge.
-
Verification: After installation, perform functional checks to ensure proper contact signaling.
10 Common FAQs (De-AI Style)
Q1: What types of contactors is the TA564-11 1TNE968901R3104 compatible with?
A1: The TA564-11 1TNE968901R3104 is designed to be used with ABB A-series and AF-series contactors, fitting easily into their auxiliary mounting positions.
Q2: Can it be used in outdoor applications?
A2: The TA564-11 1TNE968901R3104 is not rated for outdoor use unless housed in a protective enclosure due to its IP20 rating.
Q3: How many auxiliary contacts does it provide?
A3: It provides one normally open (NO) and one normally closed (NC) contact.
Q4: What is the expected lifespan of this unit?
A4: Mechanically, it can exceed 10 million operations, making it suitable for long-term industrial use.
Q5: Is any special tool needed for installation?
A5: No, it has a snap-on design and can be mounted manually onto the contactor.
Q6: Can it operate in high-temperature environments?
A6: Yes, it is rated for continuous operation from -25°C to +55°C.
Q7: What’s the maximum voltage the block can handle?
A7: It supports a rated insulation voltage of up to 690V.
Q8: Can I mount it on the side of the contactor?
A8: This particular model is designed for front mounting only.
Q9: Is this product compliant with IEC standards?
A9: Yes, it meets IEC 60947-5-1 standards for auxiliary contact blocks.
Q10: How do I identify a faulty contact in the block?
A10: Visual inspection and multimeter testing across the terminals during energized conditions will reveal if any contact is not responding properly.
6 Related Models in the Same Series or Function Range
-
ABB TA25DU-11 – Side-mounted auxiliary contact block (1NO+1NC)
-
ABB CA5-10 – Front mount auxiliary block (1NO)
-
ABB CA5-01 – Front mount auxiliary block (1NC)
-
ABB CA6-10 – Heavy-duty auxiliary block with 1NO contact
-
ABB TA16DU-11 – Compact auxiliary block (1NO+1NC)
-
ABB N22E – Auxiliary contact block for N-series contactors
6 Popular ABB Models (Same Brand, Widely Used)
| Model | Function | Voltage | Dimensions (mm) | Weight |
|---|---|---|---|---|
| A16-30-10 | Contactor (3P, 1NO aux) | 690V AC | 45 x 80 x 85 | 400 g |
| AF09-30-10 | AF-series contactor (3P, 1NO) | 690V AC | 45 x 75 x 85 | 350 g |
| TA25DU-11 | Auxiliary block (side-mount) | 690V AC | 45 x 60 x 25 | 40 g |
| OT63F3 | Disconnect switch (3-pole) | 690V AC | 70 x 110 x 60 | 600 g |
| MS165-10 | Motor starter protector | 690V AC | 45 x 90 x 80 | 500 g |
| TMAX XT1N 160 | Molded case circuit breaker | 690V AC | 105 x 160 x 75 | 1.2 kg |
