Product Overview
The ABB TC501V150 (3BSC550038R3) is a specialized I/O Speedometer Input Module designed for use in high-performance industrial automation and process control systems. It serves as a key interface for acquiring rotational speed signals—typically from tachometers or other rotating machinery sensors—and converting them into digital signals for analysis and control by ABB’s distributed control systems (DCS), such as System 800xA or Advant OCS.
Engineered for high accuracy and reliability, the TC501V150 supports a wide range of signal types and frequencies, making it ideal for real-time monitoring, feedback loops, and motion control systems where speed measurement is critical to maintaining process integrity.
Key Features
-
Dedicated interface for speedometer (tachometer) input signals
-
Accurate pulse/frequency-to-digital conversion
-
Supports a wide range of frequency input signals
-
Compatible with ABB’s System 800xA and Advant OCS control platforms
-
Noise-immune design suitable for industrial environments
-
Fast response time for high-speed control loops
-
Galvanic isolation between channels and system bus
-
DIN rail mounting for simplified installation
-
Extended temperature operating range
-
Designed for critical applications like turbines, compressors, and motors
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | I/O Speedometer Input Module |
| Model Number | TC501V150 |
| Ordering Code | 3BSC550038R3 |
| Input Type | Frequency / Pulse (tachometer signals) |
| Input Signal Range | 0.1 Hz – 50 kHz (typical) |
| Input Voltage | 5 – 24 V DC (TTL or open collector compatible) |
| Channels | 1 or 2 speed input channels (depending on configuration) |
| Measurement Accuracy | ±0.05% of full scale (typical) |
| Isolation | Galvanic isolation between field input and system bus |
| Communication Interface | System Bus (for System 800xA or Advant systems) |
| Update Rate | ≤ 1 ms (real-time control capable) |
| Power Supply Voltage | 24 V DC (supplied via backplane) |
| Power Consumption | ≤ 2.5 W |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95%, non-condensing |
| Dimensions | 100 × 30 × 200mm |
| Weight | 0.005 kg |
| Mounting Method | DIN rail |
| Protection Class | IP20 |
| Certifications | CE, UL, RoHS, EN 61131 compliant |
Industry Applications
The ABB TC501V150 is ideally suited for industrial sectors that rely on precision speed monitoring and control of rotating equipment:
-
Power Generation: Turbine and generator speed monitoring
-
Oil & Gas: Compressor and pump rotation measurement
-
Steel and Metal Processing: Speed synchronization in rolling mills
-
Pulp & Paper: Web speed control in paper machines
-
Water Treatment: Rotating decanter and aeration systems
-
Transportation: Rail systems, conveyors, and motorized equipment speed feedback
Product Advantages
-
High-speed, high-resolution input measurement for precision control
-
Rugged industrial design ensures dependable operation in harsh conditions
-
Galvanic isolation improves system safety and signal integrity
-
Compatible with ABB’s leading DCS platforms
-
Supports multiple input signal types for broad sensor compatibility
-
Compact DIN rail form factor for efficient panel integration
-
Fast signal update for use in dynamic control environments
-
Reduced installation effort thanks to standard wiring and terminal layout
-
Diagnostic integration via the system bus for easy maintenance
-
Long product lifecycle support from ABB’s automation ecosystem
Frequently Asked Questions (FAQ)
1. What is the purpose of the TC501V150 module?
It measures and converts speed signals from tachometers or similar sensors into digital signals for process control.
2. What ABB systems is it compatible with?
It works with System 800xA, Advant OCS, and related ABB DCS platforms.
3. What input signal range does it support?
It typically supports input frequencies from 0.1 Hz to 50 kHz.
4. Can it handle TTL-level inputs?
Yes, it supports 5–24 V DC inputs compatible with TTL and open collector sensors.
5. Is the input isolated from the control system?
Yes, it provides galvanic isolation to ensure signal integrity and safety.
6. How accurate is the speed measurement?
The module offers ±0.05% full-scale accuracy under normal conditions.
7. Can I use this module for turbine control?
Yes, it is well-suited for turbine speed feedback in power generation applications.
8. How is it mounted?
It uses standard DIN rail mounting for fast integration.
9. Does it support redundancy?
Redundancy is supported through the system architecture, not the module alone.
10. Is firmware upgradeable?
Firmware is managed by the ABB control system; specific firmware upgrades depend on system compatibility.
