Product Introduction
The ABB TD 951F 3BDH001020R0001 is a high-performance temperature detector designed for industrial applications. It ensures accurate and reliable temperature monitoring in harsh environments, making it suitable for power plants, oil & gas, and manufacturing industries. The device features robust construction, long-term stability, and compatibility with various control systems.
Product Specifications
| Parameter | Value |
|---|---|
| Model Number | TD 951F 3BDH001020R0001 |
| Type | Resistance Temperature Detector (RTD) |
| Temperature Range | -50°C to +500°C (-58°F to +932°F) |
| Accuracy | ±0.5°C (±0.9°F) |
| Sensor Element | Pt100 (Platinum) |
| Connection Type | 2/3/4-wire configuration |
| Protection Class | IP67 |
| Material (Housing) | Stainless Steel (AISI 316) |
| Dimensions | 22 ×110× 58 mm |
| Weight | 0.09 kg |
| Electrical Output | 4-20 mA / HART Protocol |
| Mounting | Threaded (M12, M20, or custom) |
Product Applications
The ABB TD 951F is widely used in industries requiring precise temperature measurement:
-
Power Generation: Monitoring steam turbines, boilers, and heat exchangers.
-
Oil & Gas: Downhole and pipeline temperature sensing.
-
Chemical Processing: Reaction vessel and furnace temperature control.
-
HVAC Systems: Airflow and cooling system monitoring.
-
Food & Beverage: Pasteurization and sterilization processes.
-
Automotive: Engine and exhaust temperature testing.
Product Advantages
-
High Accuracy: ±0.5°C ensures reliable data for critical processes.
-
Durable Construction: Stainless steel housing resists corrosion and mechanical stress.
-
Wide Temperature Range: Suitable for extreme cold and heat conditions.
-
Flexible Connectivity: Supports 2/3/4-wire setups for different control systems.
-
IP67 Protection: Dustproof and waterproof for harsh environments.
-
Long-Term Stability: Minimal drift over time, reducing recalibration needs.
-
HART Compatibility: Enables digital communication for smart systems.
Frequently Asked Questions (FAQ)
Q1: What is the operating temperature range of the TD 951F?
A1: It operates from -50°C to +500°C (-58°F to +932°F).
Q2: Is this sensor compatible with PLC systems?
A2: Yes, it supports 4-20 mA and HART protocol, making it PLC-compatible.
Q3: What is the response time of this RTD?
A3: Typically 2-5 seconds in air, depending on the sheath material.
Q4: Can it be used in explosive environments?
A4: Yes, with additional ATEX or IECEx certification (check specific variants).
Q5: What is the lifespan of the TD 951F?
A5: 5+ years under normal operating conditions.
Q6: Does it require calibration?
A6: Periodic calibration is recommended (annually for critical applications).
Q7: What is the wire configuration?
A7: Available in 2, 3, or 4-wire setups for different accuracy levels.
Q8: Can it be submerged in liquids?
A8: Yes, IP67 rating allows submersion up to 1 meter for 30 minutes.
Q9: Is the housing corrosion-resistant?
A9: Yes, stainless steel (AISI 316) provides excellent corrosion resistance.
Q10: How do I mount this sensor?
A10: Standard threaded mounting (M12, M20), with optional flanges.
