Product Introduction
The ABB TK801V012 3BSC950089R3 is an advanced operator panel and process interface device, carefully engineered for ABB’s Industrial IT and Symphony Plus control systems. As a vital part of Human-Machine Interface (HMI) architecture, this product offers a highly responsive display, seamless integration with process controllers, and durable design for industrial environments. The device is tailored to meet demanding operational needs, ensuring accurate monitoring and intuitive control of production processes.
The TK801V012 bridges the gap between operators and complex automated systems, combining functionality with reliability. ABB’s proven engineering expertise guarantees that this model performs consistently in power generation, chemical plants, and other critical industrial applications where system uptime and precision are essential.
Technical Parameters
| Parameter | Specification |
|---|---|
| Product Model | TK801V012 3BSC950089R3 |
| Display Type | TFT LCD |
| Power Supply | 24 V DC ±10% |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 10% – 90% (non-condensing) |
| Cable length | 1.2 m |
| Weight | 0.265 kg |
| Communication Ports | Ethernet, RS-232, USB |
| Mounting Type | Panel mounting |
| Certifications | CE, UL, RoHS |
Product Applications
The ABB TK801V012 3BSC950089R3 is widely used across multiple industries due to its versatility and robust design. Typical applications include:
-
Power generation stations for real-time process visualization and control
-
Oil and gas processing plants for alarm monitoring and data trending
-
Chemical and pharmaceutical production lines for recipe management and status feedback
-
Water treatment facilities for SCADA system integration
-
Manufacturing plants requiring centralized process supervision
-
Any industrial environment where intuitive operator control and fault diagnostics are necessary
Its ability to operate in harsh conditions makes it an essential component in both new installations and retrofitting older systems with modern HMI technology.
Product Advantages
The TK801V012 stands out due to several unique advantages:
-
High-resolution display providing sharp and clear process graphics
-
Industrial-grade durability ensuring long service life under demanding conditions
-
Flexible connectivity supporting multiple communication protocols for seamless integration
-
User-friendly interface that simplifies operator training and reduces human error
-
Compact design optimized for limited control room space without sacrificing screen size
-
Reliable ABB engineering backed by a global support network and consistent spare parts availability
These benefits collectively reduce operational downtime, enhance safety, and streamline process efficiency.
Frequently Asked Questions (FAQ)
Q1: What industries commonly use the TK801V012?
A1: Power generation, petrochemical, water treatment, and manufacturing industries.
Q2: Is the display resistant to harsh lighting conditions?
A2: Yes, it features a high-brightness TFT LCD suitable for varied lighting environments.
Q3: Does the TK801V012 support remote diagnostics?
A3: Yes, remote monitoring and diagnostics are supported via Ethernet connectivity.
Q4: What is the installation method?
A4: Panel mounting with screw fasteners ensures secure and vibration-resistant installation.
Q5: Can it be used in outdoor environments?
A5: It is designed for indoor use but can be used in protected outdoor panels if properly enclosed.
Q6: Is there built-in data logging?
A6: Yes, it supports data logging which can be exported for further analysis.
Q7: How long is the average service life?
A7: Typically over 50,000 hours of operation with proper maintenance.
Q8: Are spare parts available worldwide?
A8: Yes, ABB maintains global parts availability to reduce downtime.
Q9: Does it comply with CE and UL standards?
A9: Yes, it meets major international standards including CE and UL.
Q10: Can multiple TK801V012 units be networked together?
A10: Yes, they can be configured on the same network for distributed control and monitoring.
Recommended Models – Same Series / Related Models
-
ABB TK801V010
-
ABB TK801V011
-
ABB TK802V020
-
ABB TK802V022
-
ABB TK803V030
-
ABB TK803V031
These models offer varied screen sizes, interface options, or enhanced performance for specialized industrial tasks.
Popular Models from the Same Brand (with parameters)
| Model | Display Size | Resolution | Dimensions (mm) | Weight (kg) | Voltage |
|---|---|---|---|---|---|
| TK801V012 | 15″ | 1024 x 768 | 380 x 300 x 90 | 4.8 | 24 V DC |
| TK802V020 | 17″ | 1280 x 1024 | 410 x 330 x 95 | 5.5 | 24 V DC |
| TK802V022 | 17″ | 1280 x 1024 | 410 x 330 x 95 | 5.5 | 24 V DC |
| TK803V030 | 19″ | 1280 x 1024 | 450 x 360 x 100 | 6.2 | 24 V DC |
| TK803V031 | 19″ | 1280 x 1024 | 450 x 360 x 100 | 6.2 | 24 V DC |
| CP6202 | 15″ | 1024 x 768 | 380 x 300 x 85 | 4.5 | 24 V DC |
| CP6203 | 17″ | 1280 x 1024 | 410 x 330 x 90 | 5.3 | 24 V DC |
| CP6204 | 19″ | 1280 x 1024 | 450 x 360 x 95 | 6.1 | 24 V DC |
