ABB TK802F 3BDM000213R1 Product Introduction
The ABB TK802F 3BDM000213R1 is an industrial-grade operator terminal engineered for critical automation and control systems. Developed by ABB, a global leader in automation technologies, this model is part of the renowned Freelance DCS and Symphony Plus family, built to deliver reliable human-machine interface (HMI) functions. Designed with a rugged structure and modern touch display, it streamlines complex process operations while ensuring real-time monitoring and intuitive control.
The TK802F brings together robust construction, flexible connectivity, and user-focused ergonomics, making it ideal for demanding industrial settings where reliability and clear visual feedback are paramount.
Technical Parameters
| Parameter | Details |
|---|---|
| Model | TK802F |
| Ordering Code | 3BDM000213R1 |
| Display Size | 15-inch TFT LCD |
| Resolution | 1024 × 768 pixels |
| Input Method | Touchscreen |
| Cable length | 2 m |
| Weight | 4.2 kg |
| Power Supply | 24 V DC (±20%) |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Mounting Type | Panel mounting |
| Communication Ports | Ethernet, USB, Serial (RS-232/RS-485) |
Product Applications
The ABB TK802F 3BDM000213R1 is widely used across process industries, energy generation plants, water treatment facilities, and industrial manufacturing systems. Typical applications include:
-
Monitoring and control of distributed control systems (DCS)
-
Display and management of alarms and real-time data
-
Supervisory functions for production lines and process areas
-
Visualization of complex process graphics in control rooms
-
Seamless integration with ABB Freelance and Symphony Plus systems
-
Supporting local and remote engineering workstations for troubleshooting and maintenance
Its versatility makes it a practical choice for both new installations and modernization projects.
Product Advantages
-
Robust and Reliable: Built to withstand industrial environments with high vibration and temperature variations.
-
High-Resolution Display: Clear and detailed visualization of process data, alarms, and graphics.
-
User-Friendly Touch Interface: Enables intuitive operation and quick response during critical process events.
-
Flexible Communication: Multiple ports (Ethernet, USB, serial) support integration with diverse systems and peripherals.
-
Compact Design: Slim build allows easy installation into control panels and operator consoles.
-
Proven Compatibility: Fully compatible with ABB Freelance DCS and Symphony Plus platforms.
-
Extended Lifecycle: Designed for long-term availability, reducing the cost of ownership.
-
Low Power Consumption: Optimized power use helps reduce operating costs.
-
Ease of Maintenance: Modular design makes servicing and replacement straightforward.
-
Field-Proven Performance: Widely adopted by industries worldwide, ensuring dependable operation.
Frequently Asked Questions (FAQ)
Q1: What is the display size of the ABB TK802F?
A1: The TK802F features a 15-inch high-resolution TFT LCD display.
Q2: Which ABB systems is the TK802F compatible with?
A2: It is primarily compatible with ABB Freelance DCS and Symphony Plus systems.
Q3: Can the TK802F operate in high-temperature environments?
A3: Yes, it supports an operating temperature range of 0 °C to +50 °C.
Q4: What type of touch interface does it use?
A4: It uses a responsive touchscreen for direct operator interaction.
Q5: Does it support Ethernet connectivity?
A5: Yes, the TK802F has an Ethernet port for network integration.
Q6: What power supply does the TK802F require?
A6: It operates on 24 V DC with a ±20% tolerance.
Q7: Is the TK802F suitable for panel mounting?
A7: Absolutely; it is designed for panel mounting installations.
Q8: How heavy is the ABB TK802F?
A8: It weighs 4.2 kg.
Q9: Does ABB provide long-term support for this model?
A9: Yes, ABB supports extended lifecycle and spare part availability.
Q10: What makes the TK802F popular in industrial applications?
A10: Its reliability, integration capability, high-quality display, and user-friendly design make it a trusted choice worldwide.
Recommended Models – Same Series / Related
-
ABB TK801F
-
ABB TK803F
-
ABB TP854 3BSE025349R1
-
ABB TK850 3BDH000031R1
-
ABB TP857 3BSE066490R1
-
ABB TP870 3BSE092690R1
These models share compatibility and design philosophy, ensuring consistent integration into ABB automation solutions.
Popular ABB Models (With Key Parameters)
| Model | Display Size | Dimensions (W×H×D) | Weight | Voltage |
|---|---|---|---|---|
| TP854 3BSE025349R1 | 15-inch | 384×305×66 mm | 4.1 kg | 24 V DC |
| TP857 3BSE066490R1 | 19-inch | 450×360×75 mm | 5.5 kg | 24 V DC |
| TP870 3BSE092690R1 | 21.5-inch | 530×350×75 mm | 6.0 kg | 24 V DC |
| TK801F | 10.4-inch | 276×212×60 mm | 3.2 kg | 24 V DC |
| TK803F | 12.1-inch | 312×240×62 mm | 3.5 kg | 24 V DC |
| CP651 | 12-inch | 305×245×65 mm | 3.8 kg | 24 V DC |
| CP635 | 6-inch | 200×150×55 mm | 2.2 kg | 24 V DC |
| CP665 | 15-inch | 384×305×66 mm | 4.3 kg | 24 V DC |
