Product Overview
The ABB UCD240A101 (3BHE022287R0101) is a Communication Controller Board designed to facilitate high-speed, reliable communication in industrial automation systems. It is specifically developed for integration within ABB’s control systems and automation platforms, enabling seamless data exchange between various devices, controllers, and field modules. The UCD240A101 is part of ABB’s comprehensive suite of communication solutions, ensuring real-time data transmission across Ethernet, serial communication, and fieldbus networks, which are essential for modern industrial environments.
This modular communication controller is engineered to support redundant communication links, improving system reliability, and to integrate with a wide range of ABB and third-party equipment, making it suitable for complex industrial applications where performance, flexibility, and scalability are key.
Key Features
-
Central Communication Hub for ABB automation systems, ensuring smooth data transmission across controllers and I/O devices
-
Multiple Communication Interfaces: Ethernet, serial, and fieldbus for versatile integration with various devices
-
Supports Redundant Communication Paths to ensure high availability and fault tolerance
-
Real-Time Data Processing for efficient system control and monitoring
-
Modular and Scalable Design for easy integration into existing control systems
-
High-Speed Data Transfer capabilities for critical control applications
-
Enhanced Diagnostics via built-in LED indicators for easy troubleshooting
-
Compact Form Factor suitable for DIN rail mounting or panel mounting
-
Industrial-Grade Durability, designed to operate in harsh industrial environments with wide temperature and humidity ranges
-
Compliant with Global Standards: CE, RoHS, UL, IEC for safety and quality
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Communication Controller Board |
| Model Number | UCD240A101 |
| Ordering Code | 3BHE022287R0101 |
| Supported Protocols | Ethernet, Serial, Fieldbus |
| Number of Ports | 4 (depending on the configuration and application) |
| Input Voltage | 24V DC ±10% |
| Data Transfer Rate | Up to 1 Gbps (depending on interface and network conditions) |
| Processor | Integrated microcontroller for high-speed communication |
| Mounting Type | DIN rail or Panel mountable |
| Dimensions | 247 x 30 x 270mm |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Weight | 0.92 kg |
| Compliance Standards | CE, RoHS, UL, IEC 61158 |
| Diagnostics | LED indicators for operational status and fault diagnostics |
| Redundancy | Yes, supports redundant communication paths |
| Protection Class | IP20 (when installed in a panel or enclosure) |
Industry Applications
The ABB UCD240A101 Communication Controller Board is ideal for industries where high-speed communication and reliable system integration are essential, including:
-
Industrial Automation – Used as a central communication hub between controllers, I/O modules, and field devices in automated production lines and manufacturing systems
-
Power Generation – Enables communication in SCADA and DCS systems for real-time monitoring and control in power plants
-
Oil & Gas – Facilitates communication between offshore platforms and central control stations for efficient operation monitoring
-
Water Treatment – Used for process control and data acquisition in water and wastewater treatment facilities
-
Chemical and Petrochemical – Supports communication between devices in hazardous environments requiring robust, fault-tolerant systems
-
Automotive Manufacturing – Integrates with robotic and control systems for automated assembly lines and production plants
-
Renewable Energy – Manages data transmission in wind and solar power generation systems
Product Advantages
-
Multiple communication protocols (Ethernet, serial, and fieldbus) provide flexible and reliable data exchange across industrial systems
-
Redundant communication paths ensure higher system uptime and reliability in critical applications
-
Modular design enables easy integration with a variety of ABB and third-party devices
-
Compact form factor allows for space-saving installation in control panels and automation racks
-
Real-time data processing capabilities ensure fast, responsive control and monitoring of processes
-
Industrial-grade durability ensures long-term performance in harsh environments with wide temperature and humidity ranges
-
Enhanced diagnostics through LED indicators for easy fault detection and troubleshooting
-
Compliance with international safety and quality standards ensures safe and reliable operation worldwide
-
Scalable design for future expansion and integration with additional devices or communication networks
Frequently Asked Questions (FAQ)
1. What communication protocols does the UCD240A101 support?
It supports Ethernet, serial communication, and fieldbus protocols, offering flexibility in communication with various devices.
2. How many communication ports are available on the UCD240A101?
The board supports 4 ports in total, depending on the specific configuration and application.
3. Does the UCD240A101 support redundant communication?
Yes, the UCD240A101 supports redundant communication paths, enhancing system reliability and fault tolerance.
4. What is the maximum data transfer rate?
The board supports data transfer rates of up to 1 Gbps, depending on the network and interface used.
5. What is the required voltage for operation?
The board operates with a 24V DC ±10% power supply.
6. Can the UCD240A101 be used in outdoor environments?
This board is designed for indoor use in industrial control environments. If used outdoors, it should be installed in a protective enclosure.
7. How is the UCD240A101 mounted?
It can be mounted on a DIN rail or panel-mounted based on installation needs.
8. What diagnostic features are available?
The board includes LED indicators for real-time monitoring of operational status and quick fault diagnostics.
9. What are the operating temperature limits for the UCD240A101?
The board operates within a temperature range of -20°C to +70°C.
10. Is the UCD240A101 compatible with other ABB control systems?
Yes, it integrates seamlessly with various ABB automation systems and I/O modules.
Related ABB Communication Products
| Model | Description |
|---|---|
| UCD240A102 | A similar version of the UCD240A101, supporting additional protocols |
| CI820 | Communication interface module for S800 I/O modules |
| UMC1000 | Universal Modbus Communication Gateway for ABB systems |
| CI840A | Interface module with Ethernet and serial communication support |
| SDCS-PIN-205C | Power interface for ABB drive systems |
| TB820 | Terminal base with communication interfaces for I/O systems |
Popular ABB Automation Products
| Model | Description |
|---|---|
| System 800xA | ABB’s Distributed Control System (DCS) for integrated control |
| S800 I/O | Modular I/O system for distributed process control |
| AC500 PLC | Scalable PLC for process control and automation |
| CP600 HMI | Human-machine interface for real-time process control |
| CI840 | Ethernet communication interface for ABB I/O modules |
| SDCS-PIN-205C | Power interface module for ABB drive systems |
