ABB UG A469 AE02 HIEE200024R0002 Ethernet Switch

Product Introduction

The ABB UG A469 AE02 HIEE200024R0002 Ethernet Switch is an industrial-grade managed network switch engineered to provide secure, high-speed Ethernet connectivity within ABB automation systems. Designed specifically for demanding industrial environments, it serves as the backbone for reliable data communication in power plants, manufacturing facilities, and process automation networks.

This Ethernet switch offers high port density and supports gigabit speeds, ensuring minimal latency and robust communication between controllers, I/O devices, and supervisory systems. Its ruggedized construction, redundant power inputs, and advanced network management functions make it suitable for continuous 24/7 operation in harsh conditions with strong electromagnetic interference or extreme temperature variations.

Technical Specifications

Applications

• Power Generation & Distribution: Ensures secure and fast communication between control systems and SCADA networks in substations and power plants.

• Industrial Automation: Provides stable network infrastructure for PLCs, DCS, and robotic systems.

• Transportation Systems: Reliable backbone for railway signaling, traffic monitoring, and intelligent transport networks.

• Oil & Gas Facilities: Supports redundant, high-availability networks in offshore and onshore installations.

• Water & Wastewater Management: Enables real-time data transfer for pumps, sensors, and treatment plant controllers.

• Smart Manufacturing: Integrates seamlessly with Industry 4.0 environments requiring high-bandwidth communication.

Advantages

• Industrial Reliability: Designed to withstand extreme temperature ranges, high vibration, and electrical noise.

• High-Speed Performance: Non-blocking switching capacity up to 24 Gbps for real-time data transmission.

• Redundant Power & Network: Dual power inputs and support for ring redundancy ensure continuous operation.

• Advanced Security: Supports SNMP v3, SSH, and network segmentation to protect against unauthorized access.

• Easy Management: Web-based interface, CLI, and SNMP allow flexible configuration and monitoring.

• Scalability: Modular SFP ports support fiber connectivity and network expansion without downtime.

FAQ

1. Which network redundancy protocols are supported?
   It supports RSTP, MSTP, ERPS, and ABB proprietary redundancy for high availability.

2. Does it provide VLAN and QoS features?
   Yes, IEEE 802.1Q VLAN and 802.1p QoS are fully supported for traffic segmentation and prioritization.

3. What management interfaces are available?
   Configuration can be done through Web GUI, CLI via console/Telnet/SSH, and SNMP v1/v2c/v3.

4. Can the switch operate in extreme temperatures?
   Yes, it is rated for –40 °C to +75 °C continuous operation.

5. What is the maximum switching capacity?
   The switch provides a non-blocking switching capacity of 24 Gbps.

6. Is redundant power input supported?
   Yes, dual 24 V DC (18–36 V) power inputs are provided for redundancy.

7. How is network security handled?
   Through SNMP v3 authentication, SSH encryption, and configurable access control lists.

8. Are fiber connections supported?
   Yes, 2 SFP slots allow for flexible single-mode or multi-mode fiber uplinks.

9. Can the switch be integrated into ABB 800xA or similar control systems?
   Yes, it integrates seamlessly with ABB 800xA and other ABB automation platforms.

10. How is firmware upgraded?
    Firmware updates can be applied through the web interface or via TFTP/FTP upload.
