Product Introduction
The GE IC200PER102 Power Supply is a dedicated power module designed for the VersaMax PLC system, providing reliable DC power to the I/O modules and control components. As an essential element of the PLC infrastructure, the IC200PER102 ensures that all connected modules receive a stable and regulated voltage, which is critical for maintaining consistent operation, data integrity, and overall system reliability in industrial environments.
The IC200PER102 is engineered to operate under harsh industrial conditions, including electrical noise, voltage fluctuations, and varying load demands. It incorporates built-in protection mechanisms to prevent overcurrent, short circuits, and reverse polarity conditions, which can otherwise compromise the performance of sensitive PLC modules.
Designed for ease of installation, this power supply can be snapped directly into the VersaMax I/O rack, aligning with other modules without requiring additional mounting hardware. It supports both initial system deployment and incremental expansion, allowing industrial facilities to scale operations efficiently while maintaining system stability.
The module’s high-quality construction and industrial-grade components make it ideal for control panels in manufacturing, process automation, energy, and utility sectors, ensuring continuous and safe operation of critical automation processes.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | IC200PER102 |
| Type | Power Supply Module |
| Output Voltage | 5 VDC or 24 VDC selectable |
| Output Current | 2 A at 5 VDC, 1.5 A at 24 VDC |
| Input Voltage | 100–240 VAC, 50/60 Hz |
| Efficiency | 85% typical |
| Protection | Overcurrent, Short Circuit, Reverse Polarity |
| Mounting Orientation | Snap-in, compatible with VersaMax racks |
| Dimensions (L × W × H) | 110 x 90 x 105 mm |
| Weight | 0.26 kg |
| Operating Temperature | 0–60 °C |
| Storage Temperature | –40 to 85 °C |
| Certifications | UL, CE |
| Cooling | Convection (no fan) |
| Isolation Voltage | 1500 VDC between input and output |
Product Applications
The IC200PER102 Power Supply is suitable for a variety of industrial automation scenarios:
-
PLC System Operation: Provides regulated DC power to all VersaMax modules, ensuring consistent and reliable control system performance.
-
Process Automation: Powers sensors, actuators, and discrete I/O modules for manufacturing process control.
-
Energy and Utility Control Panels: Supplies stable voltage to critical instrumentation and automation devices.
-
Incremental System Expansion: Supports additional I/O modules by providing reliable power without overloading existing circuits.
-
Industrial Control Panels: Used in assembly lines, chemical plants, and water treatment facilities to maintain continuous, stable operation.
-
Test and Maintenance Systems: Can be integrated into temporary or mobile test racks to verify system integrity without full deployment.
-
Safety-Critical Systems: Provides redundancy and stability for control applications where power reliability is paramount.
Product Advantages
-
Stable Voltage Supply: Ensures reliable operation of all connected I/O modules and PLC components.
-
High Efficiency: Designed to minimize power loss and heat generation.
-
Industrial-Grade Protection: Built-in overcurrent, short circuit, and reverse polarity protection for enhanced safety.
-
Plug-and-Play Installation: Snap-in design simplifies installation and replacement in VersaMax racks.
-
Compact Design: Saves space within control panels while providing robust power delivery.
-
Wide Input Voltage Range: Supports global applications with 100–240 VAC input.
-
Fanless Cooling: Convection cooling design ensures silent, maintenance-free operation.
-
Certifications: UL and CE certified for industrial standards compliance.
-
Flexible Application: Suitable for both new deployments and system expansions.
-
Durable Construction: Industrial-grade materials ensure longevity under harsh conditions.
Frequently Asked Questions
-
What output voltages does the IC200PER102 provide?
The module supports 5 VDC or 24 VDC output, selectable to match the application requirements. -
What is the maximum output current of the module?
It delivers up to 2 A at 5 VDC and 1.5 A at 24 VDC, suitable for standard VersaMax I/O loads. -
Does the module provide protection against electrical faults?
Yes, it includes overcurrent, short circuit, and reverse polarity protection, ensuring system safety. -
Can the power supply be installed in any orientation?
Yes, the snap-in design allows vertical or horizontal mounting in the VersaMax rack. -
What input voltage ranges are supported?
The IC200PER102 accepts 100–240 VAC, 50/60 Hz, making it suitable for global industrial use. -
Is active cooling required for this module?
No, the module is designed for convection cooling and operates efficiently without fans. -
Can this power supply handle temporary high-load conditions?
Yes, it has a short-term tolerance for peak currents, providing reliable operation during transient demands. -
Is the module suitable for critical control systems?
Absolutely, its regulated voltage and protection features make it ideal for safety-critical and industrial automation systems. -
What certifications does this module have?
It is UL and CE certified, complying with industrial safety and quality standards. -
Can the module be replaced without shutting down the entire system?
In most configurations, hot-swap is not recommended, but installation and replacement are straightforward during scheduled maintenance periods.
Related Models
| Model Number | Description | Type |
|---|---|---|
| IC200PER101 | 5 VDC Power Supply Module | Power Supply |
| IC200PER103 | 24 VDC High-Current Power Supply | Power Supply |
| IC200PER104 | Redundant Power Supply Module | Power Supply |
| IC200PER105 | Rack-Mount Power Supply | Power Supply |
| IC200MDL640 | Discrete Input Module | Digital Input |
| IC200MDL650 | Discrete Output Module | Digital Output |
