Product Introduction
The ABB US B030 AE02 HIEE200072R2 is a high-performance power supply module designed for industrial automation systems. It is part of ABB’s trusted range of control system components and is typically used in distributed control systems (DCS) to provide reliable and stable power to controllers, I/O modules, and communication units.
Built to meet the demanding standards of process and manufacturing industries, this module ensures high operational availability, safety, and system continuity. The module is engineered with a rugged structure, enabling it to function efficiently even in harsh industrial environments such as oil and gas facilities, chemical processing plants, and power stations.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | US B030 AE02 |
| Part Number | HIEE200072R2 |
| Manufacturer | ABB |
| Module Type | Power Supply Module |
| Input Voltage Range | 85 – 264 VAC / 100 – 300 VDC |
| Output Voltage | 24 VDC regulated |
| Output Current | Up to 5 A (depending on load) |
| Output Power | Approximately 120W |
| Efficiency | ≥ 85% |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Cooling Method | Natural convection |
| MTBF | > 200,000 hours |
| Protection Features | Over-voltage, Overload, Short-circuit |
| Mounting | DIN rail mounting |
| Interface | Terminal block connectors |
| Dimensions (W x H x D) | 90 x 130 x 160 mm |
| Weight | 0.95 kg |
| Certifications | CE, RoHS, UL, CSA compliant |
Applications
The ABB US B030 AE02 HIEE200072R2 Power Supply Module is applied in a wide range of industrial scenarios where continuous and clean power delivery is critical:
-
Process automation for continuous manufacturing systems
-
Distributed Control Systems (DCS) power supply
-
SCADA systems for remote monitoring and control
-
Oil and gas industry, including refineries and offshore rigs
-
Energy generation and power distribution substations
-
Chemical and pharmaceutical production lines
-
Heavy industrial machinery requiring regulated DC power
Product Advantages
-
High reliability designed for 24/7 continuous operation in mission-critical applications
-
Wide input voltage range supports both AC and DC sources, enhancing compatibility
-
Compact and space-saving design suitable for control panels
-
Comprehensive protection features to safeguard connected components
-
Quick integration with ABB automation systems through standard interfaces
-
Extended service life and low maintenance due to high-quality construction
Frequently Asked Questions (FAQ)
1. What system is the US B030 AE02 module designed for?
It is primarily used in ABB Symphony and Advant DCS systems but may also be compatible with other industrial control platforms.
2. What is the input voltage range of this module?
It supports 85–264 VAC and 100–300 VDC, making it flexible for various power sources.
3. Is this module DIN rail mountable?
Yes, it supports standard DIN rail mounting for easy installation.
4. What kind of protections does the module offer?
It includes over-voltage, overload, and short-circuit protections.
5. What is the MTBF (Mean Time Between Failures)?
The MTBF is more than 200,000 hours under standard operating conditions.
6. Can this module be used in extreme temperatures?
Yes, it operates between -20°C and +60°C and can be stored between -40°C and +85°C.
7. Is the output voltage regulated?
Yes, the module provides a stable and regulated 24 VDC output.
8. Does it have status indicators?
Most units include LED indicators for power and fault conditions.
9. Is the ABB US B030 AE02 hot-swappable?
No, the system should be powered down before replacing the module to ensure safety.
10. Is the power supply module certified?
Yes, it complies with CE, UL, CSA, and RoHS standards.
Related Models (Same Series or Similar Function)
| Model | Part Number | Description |
|---|---|---|
| US B030 AE01 | HIEE200071R1 | Power Supply Module, similar design |
| US B040 AE02 | HIEE200080R2 | Higher capacity power supply module |
| US C500 AE02 | HIEE305118R2 | Power module with expanded output range |
| 3BSE008522R1 | PM864AK01 | CPU module compatible with US-series modules |
| 07KT98 GJR5253100R3260 | I/O processor module for ABB control systems | |
| 3BSE011316R1 | PM865K01 | High-performance redundant CPU module |
Popular ABB Models (Other Product Categories)
| Model | Part Number | Function |
|---|---|---|
| CI854AK01 | 3BSE030220R2 | Profibus-DP communication interface |
| PM864AK01 | 3BSE018161R1 | CPU module for AC 800M control systems |
| AI810 | 3BSE008516R1 | Analog input module for ABB DCS |
| DO810 | 3BSE008510R1 | Digital output module, 16 channel |
| DI810 | 3BSE008508R1 | Digital input module, 16 channel |
| CP451-L | 1SBP260191R1001 | ABB Control Panel CPU unit |
