Product Introduction
The ABB XV C767 AE102 3BHB007209R0101 is an advanced current monitoring board designed to provide accurate and reliable measurement of electrical currents in a variety of industrial applications. It is equipped with high-performance features for real-time data analysis and fault detection, ensuring optimal operation and protection of electrical systems. This device integrates seamlessly with other ABB systems, making it an essential component in energy management and automation solutions.
Product Parameters
The following table outlines the technical specifications of the ABB XVC767AE102 current monitoring board.
| Parameter | Specification |
|---|---|
| Model Number | XV C767 AE102 3BHB007209R0101 |
| Input Voltage Range | 24V DC |
| Current Monitoring Range | 0 – 100A |
| Dimensions (L × W × H) | 220 × 100 × 25 mm |
| Weight | 0.2 kg |
| Operating Temperature | -10°C to +60°C |
| Response Time | 10 ms |
| Accuracy | ±1% |
| Communication Interface | Modbus RTU |
| Mounting Type | DIN Rail Mount |
| Protection Class | IP20 |
Product Applications
The ABB XV C767 AE102 current monitoring board is utilized in a wide range of applications, including but not limited to:
-
Industrial Automation: Monitoring and controlling currents in automated systems.
-
Electric Motor Protection: Ensuring safe operation of motors by detecting overcurrent conditions.
-
Power Distribution Systems: Protecting circuits and ensuring optimal power management.
-
Renewable Energy Systems: Monitoring electrical performance in solar and wind power setups.
-
Building Management Systems: Integrating with larger systems for energy efficiency and fault detection.
-
Robotics and Process Control: Precise current measurement for robots and manufacturing processes.
Product Advantages
-
High Accuracy: With an accuracy of ±1%, the board delivers precise current measurements, helping to avoid costly downtime or system failures.
-
Fast Response Time: The 10 ms response time allows for immediate detection of irregularities or faults in the system, ensuring swift corrective actions.
-
Flexible Communication Interface: Featuring Modbus RTU, the device allows easy integration into existing networks, providing centralized monitoring and control.
-
Robust Design: The device is designed to withstand harsh industrial environments, with an operating temperature range from -10°C to +60°C and an IP20 protection class.
-
Easy Installation: Its compact size and DIN rail mounting ensure a quick and straightforward setup.
-
Energy Efficiency: By monitoring and optimizing current flow, the device helps improve overall energy efficiency in electrical systems.
FAQ
1. What is the maximum current range of the ABB XV C767 AE102?
The ABB XV C767 AE102 supports a current monitoring range from 0 to 100A, making it suitable for a wide range of applications.
2. What communication protocol does this device use?
The device utilizes Modbus RTU as its communication protocol, enabling easy integration into industrial networks for centralized monitoring and control.
3. How accurate is the current monitoring capability of this device?
The device offers an accuracy of ±1%, ensuring highly precise current measurements to prevent system failures or inefficiencies.
4. What is the response time for detecting current variations?
The response time for detecting current changes is 10 ms, allowing for rapid fault detection and corrective actions.
5. Can this product be used for motor protection?
Yes, the ABB XV C767 AE102 is ideal for motor protection, as it can monitor the current to detect overcurrent conditions and protect the motor from damage.
6. What is the operating temperature range for the ABB XV C767 AE102?
The device operates within a temperature range of -10°C to +60°C, making it suitable for a variety of industrial environments.
7. Is this device suitable for integration into renewable energy systems?
Yes, the ABB XV C767 AE102 is well-suited for renewable energy systems, including solar and wind power installations, where current monitoring is crucial for system optimization.
8. What are the mounting options for this current monitoring board?
The device is designed for DIN rail mounting, ensuring easy and secure installation within control panels or electrical enclosures.
9. What are the power supply requirements for this device?
The ABB XV C767 AE102 operates on a 24V DC input, which is a standard voltage for many industrial devices.
10. How can the ABB XV C767 AE102 be integrated into a building management system?
The device can be integrated into a building management system using its Modbus RTU interface, enabling seamless communication and centralized monitoring of electrical systems within the building.
