ABB XVC768AE101 3BHB007211R0101 Current Measuring Instrument

Product Overview

The ABB XVC768AE101 (Part Number: 3BHB007211R0101) is a precision current measuring instrument designed for use in ABB drive systems and automation equipment. It enables accurate real-time measurement and monitoring of current in high-performance industrial environments. The module plays a critical role in closed-loop control, fault detection, and overall system diagnostics.

Specifically engineered for compatibility with ABB’s drive and control platforms, the XVC768AE101 delivers consistent performance, long-term reliability, and seamless system integration.

Key Features

• Accurate current measurement for motor drives and control systems

• Fully compatible with ABB drive and automation products

• Rugged industrial design for harsh environments

• Low signal latency to support real-time feedback loops

• Diagnostic capabilities to support predictive maintenance

• DIN rail mountable for quick and secure installation

• High EMC immunity for reliable operation in noisy environments

Technical Specifications

Industry Applications

• Motor Drives – Precise current feedback for vector control and torque regulation

• Power Conversion Systems – Monitoring and control in converters and inverters

• Factory Automation – Current sensing for machines and production lines

• Energy Management Systems – Current tracking for efficiency optimization

• Process Control – Real-time monitoring in continuous and batch operations

• Transportation & Traction – Load control in electric vehicle and rail systems

Advantages

• Real-Time Measurement – Enables precise control and responsive system behavior

• ABB System Integration – Seamlessly integrates with ABB drive and controller platforms

• Compact Design – Suitable for high-density cabinet installations

• Robust Construction – Withstands industrial stress and electromagnetic interference

• Predictive Maintenance Support – Enables trend analysis and early fault detection

• Plug-and-Play Design – Reduces commissioning time and wiring errors

Frequently Asked Questions (FAQ)

1. What does the XVC768AE101 measure?
   It measures electrical current, typically for drive and motor control systems.

2. Which ABB systems is it compatible with?
   It integrates with a variety of ABB drives and automation controllers.

3. Is the output analog or digital?
   The output method depends on the host system’s configuration; typically analog for feedback.

4. What is the typical accuracy?
   The accuracy is generally ±1% or better depending on installation and system tuning.

5. How is the module mounted?
   It supports both DIN rail and panel mounting options.

6. What are its environmental tolerances?
   It operates from -10°C to +55°C and stores between -40°C and +85°C.

7. Does it support fault diagnostics?
   Yes, diagnostic features are available for integration into predictive maintenance systems.

8. Is it plug-and-play with ABB drives?
   Yes, it is optimized for seamless ABB system integration.

9. Does it support fast control loops?
   Yes, it offers fast signal response suitable for real-time applications.

10. What certifications does it hold?
    CE and RoHS compliant; other certifications may depend on regional variants.
