ABB YPK 110E YT204001-FH Parallel Bus Communication Slave Module

Company Information
E-mail		[email protected]
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The ABB YPK 110E YT204001-FH Parallel Bus Communication Slave Module is a high-performance communication interface designed for distributed industrial automation systems. It serves as a key component in parallel bus architectures, acting as a slave unit that enables precise data exchange between control systems, field devices, and monitoring units. This module is built to provide stable and high-speed communication under harsh industrial environments, ensuring synchronization and reliability for process control and monitoring applications.

The YPK 110E module is widely used in ABB’s industrial control platforms where real-time data acquisition, system coordination, and inter-device communication are essential. Its robust design, modular architecture, and high electromagnetic immunity make it a preferred choice for automation systems in sectors such as energy, manufacturing, and process industries.

---

Technical Specifications

---

Product Applications

The ABB YPK 110E module is designed for use in automation systems where reliable and synchronized communication is vital. It supports high-speed parallel data transmission, making it ideal for large-scale and high-density process control environments.

Typical applications include:

• Distributed Control Systems (DCS): For inter-module communication and signal synchronization.

• Programmable Logic Controller (PLC) networks: Acts as a slave interface for connecting peripheral devices to the main processor.

• Industrial process automation: Provides stable communication between field sensors, actuators, and supervisory systems.

• Power generation and distribution: Ensures fast data transfer and control feedback in substations and power plants.

• Manufacturing systems: Enables synchronized control across robotic cells and production lines.

---

Product Advantages

The ABB YPK 110E YT204001-FH offers a combination of performance, flexibility, and reliability that enhances industrial automation efficiency.

Key advantages include:

• High-Speed Parallel Communication: Enables efficient, low-latency data transfer for real-time control.

• Robust Isolation: Protects system integrity against electrical noise and transient voltage spikes.

• Wide Environmental Tolerance: Designed to operate under a wide temperature range and industrial humidity levels.

• Seamless Integration: Fully compatible with ABB’s industrial control and automation platforms.

• Enhanced Diagnostic Capabilities: Built-in LEDs and diagnostic ports simplify fault detection and system maintenance.

• Long-Term Reliability: Designed with high-quality components for continuous operation in demanding environments.

---

FAQ

1. What communication protocol does the ABB YPK 110E module support?
   It supports parallel bus communication protocol for high-speed and synchronous data exchange within ABB control systems.

2. How does the module ensure reliable data integrity?
   The module uses differential signaling, shielding, and internal error checking mechanisms to maintain data accuracy and reduce transmission errors.

3. Is the YPK 110E compatible with ABB’s DCS systems?
   Yes, it is fully compatible with ABB Distributed Control Systems, enabling efficient integration and communication with other ABB modules.

4. What type of isolation is provided between the control and field circuits?
   The module features galvanic isolation rated at 500 V DC to protect internal circuitry and connected devices.

5. Can this module handle both analog and digital signals?
   The YPK 110E primarily handles digital parallel data transmission but can interface with analog-to-digital converter boards when required.

6. What are the diagnostic features available?
   It includes front-panel LED indicators for power, communication status, and fault conditions, allowing quick troubleshooting.

7. How does the module manage synchronization with the main controller?
   The unit uses synchronized clocking signals from the master device to ensure real-time data alignment across all communication nodes.

8. What type of mounting options are supported?
   It can be installed on a DIN rail or within a modular rack frame for flexible integration into control cabinets.

9. What protection measures are implemented against EMI?
   The module incorporates EMI filters, shielded connectors, and grounded PCB design to ensure immunity to industrial electrical noise.

10. Is firmware upgrading supported for this module?
    Yes, firmware can be updated through a service port or system interface, ensuring compatibility with future ABB software revisions.

---
