Product Introduction
The Allen-Bradley 1606-XL60D DC/DC Converter is a compact and reliable industrial module designed to convert DC input voltage to a stable 24 V DC output. Part of the 1606-XL Series, this converter provides efficient power conversion, low ripple, and robust protection for automation and control systems.
This DC/DC converter is ideal for mobile or battery-powered industrial equipment, machinery, and vehicles, where input DC voltage may vary. Its slim and lightweight design allows installation in tight control cabinets, while maintaining high reliability and stability for connected PLCs, sensors, actuators, and control devices.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | 1606-XL60D DC/DC Converter |
| Series | 1606-XL Series |
| Input Voltage | 14–32.4 V DC |
| Output Voltage | 24 V DC |
| Output Power | 92 W |
| Output Current | Up to 3.8 A |
| Efficiency | Up to 90% |
| Ripple and Noise | ≤ 50 mV peak-to-peak |
| Operating Temperature Range | -25°C to +70°C |
| Cooling | Convection |
| Protections | Overvoltage, overcurrent, short-circuit |
| Mounting Type | DIN Rail / Panel Mount |
| Dimensions | 32 × 124 × 102 mm |
| Weight | 0.425 kg |
Applications
The 1606-XL60D DC/DC Converter is suitable for industrial and mobile applications requiring reliable DC power conversion:
-
Mobile Automation: Powers PLCs, sensors, and actuators in vehicles and battery-powered equipment.
-
Industrial Machinery: Provides stable 24 V DC to control modules and instrumentation.
-
Robotics and Assembly Lines: Converts variable DC input to stable output for controllers and actuators.
-
Energy Systems: Powers monitoring and control devices from variable DC sources.
-
Transportation and Material Handling: Supplies control systems for conveyors, automated vehicles, and safety devices.
-
Compact Control Cabinets: Ideal where space is limited but stable DC conversion is required.
Advantages
-
Reliable DC/DC Conversion: Converts variable DC input (14–32.4 V) to stable 24 V DC output.
-
Compact and Lightweight: Slim design (32 mm width) fits tight control cabinets.
-
High Efficiency: Up to 90% efficiency reduces energy loss and heat generation.
-
Robust Protection: Overvoltage, overcurrent, and short-circuit protections safeguard both the module and connected devices.
-
Low Ripple and Noise: ≤ 50 mV peak-to-peak ensures clean power for sensitive electronics.
-
Wide Temperature Range: Operates reliably from -25°C to +70°C.
-
Flexible Mounting: Supports DIN rail or panel installation.
-
Mobile-Ready: Designed for variable DC input applications in vehicles or battery-powered systems.
