Allen Bradley 1746-IM4 Digital Input Module

Product Introduction

The Allen Bradley 1746-IM4 Digital Input Module is an industrial AC digital input module designed for reliable monitoring of high-voltage AC signals in SLC 500 PLC systems. It provides 4 isolated AC digital input points, making it suitable for applications where lower input density and high electrical robustness are required.

Designed for 170–255 VAC input signals, the 1746-IM4 allows direct connection to industrial AC devices such as switches, relays, and contact outputs. Its rack-mountable design ensures seamless integration into standard SLC 500 control systems.

---

Product Specifications

---

Applications

• Used in SLC 500 PLC systems for AC digital signal acquisition

• Monitors AC switches, relay contacts, and control signals

• Applied in industrial machinery and process control panels

• Suitable for power control and utility automation systems

• Used in manufacturing environments with high-voltage AC logic

• Integrated into distributed control and monitoring systems

---

Advantages

• High-voltage AC input support, enabling direct connection to field devices

• Robust industrial design, suitable for harsh electrical environments

• Reliable signal detection, ensuring accurate AC input monitoring

• Compact 4-point configuration, ideal for low-density input requirements

• Integrated noise suppression, improving system stability

• Seamless compatibility with Allen Bradley SLC 500 PLC platforms

• Continuous-duty capability, supporting long-term operation

FAQ

1. What type of input signals does this module support?
   It supports high-voltage AC digital input signals within the 170–255 VAC range.

2. How many digital input points are available?
   The module provides 4 independent AC digital input points.

3. Is this module compatible with SLC 500 PLC systems?
   Yes, it is fully compatible with SLC 500 rack-based PLC systems.

4. What types of field devices can be connected to this module?
   AC switches, relay contacts, contactors, and other AC control devices.

5. Does the module support both 50 Hz and 60 Hz operation?
   Yes, it supports both 50 Hz and 60 Hz AC input signals.

6. Is this module suitable for industrial control panels?
   Yes, it is commonly used in industrial control and power distribution panels.

7. How does the module handle electrical noise?
   Integrated surge suppression and filtering help ensure stable signal acquisition.

8. Can this module operate continuously in industrial environments?
   Yes, it is designed for continuous-duty industrial operation.

9. Is the module rack mountable?
   Yes, it is designed for installation in standard SLC 500 PLC racks.

10. What applications benefit most from this module?
    Applications requiring reliable monitoring of high-voltage AC signals with low input density.
