Allen Bradley 1746-NIO4V Combination Analog I/O Module

Product Introduction

The Allen-Bradley 1746-NIO4V is a combination analog input/output module designed for the SLC 500 programmable controller platform. It provides high-resolution analog signal processing, allowing precise monitoring and control of industrial processes within a compact modular PLC system.

This module integrates two differential analog inputs and two analog outputs, supporting both voltage and current signal types. With an integrated 24 VDC supply, it simplifies field device integration and reduces external power requirements. The design focuses on accuracy, stability, and compatibility with industrial automation environments where reliable analog performance is essential.

---

Product Specifications

---

Applications

• High-precision process monitoring in industrial automation systems

• Analog control applications for valves, actuators, and regulated devices

• Differential signal measurement, improving accuracy in electrically noisy environments

• Integration within SLC 500 PLC systems for compact analog I/O expansion

• Closed-loop control systems requiring stable and high-resolution analog performance

---

Advantages

• High-resolution analog processing, enabling accurate measurement and control

• Differential input design, reducing noise and improving signal integrity

• Integrated 24 VDC supply, simplifying field wiring and device power requirements

• Compact modular form, fully compatible with SLC 500 chassis

• Supports both input and output functions, reducing the need for separate modules

• Reliable industrial performance, suitable for continuous operation

FAQ

1. What type of analog signals can this module process?
   It supports differential voltage and current inputs, along with two analog outputs.

2. How many total I/O points are available?
   The module provides four points: two inputs and two outputs.

3. Why are differential inputs used in this module?
   Differential inputs improve accuracy and reduce the impact of electrical noise.

4. Does the module provide power for field devices?
   Yes, it includes an integrated 24 VDC supply for connected devices.

5. Is the module suitable for high-resolution measurements?
   Yes, it is designed for high-resolution analog signal conversion.

6. Can it be installed in any SLC 500 chassis?
   Yes, it is compatible with standard SLC 500 modular PLC slots.

7. What is the typical current consumption?
   The module draws approximately 115 mA from the backplane supply.

8. Is it suitable for closed-loop control applications?
   Yes, its combined input and output capability supports closed-loop systems.

9. How does the module handle industrial electrical noise?
   Differential inputs and internal filtering help maintain stable signal integrity.

10. What maintenance is required during operation?
    Only periodic inspection of wiring and environmental conditions is recommended.
