Allen Bradley 1746-NR8 RTD Resistance Analog Input Module

Product Introduction

The Allen-Bradley 1746-NR8 is a high-precision RTD resistance analog input module designed for the SLC-500 system. Engineered for demanding industrial environments, this module provides reliable and accurate temperature measurement across eight separate RTD channels. Its open-style design allows easy integration into existing SLC-500 racks while maintaining a compact footprint.

Built to endure industrial conditions, the 1746-NR8 ensures minimal signal interference, fast response times, and precise temperature readings. It supports a wide range of RTD types and wiring configurations, making it suitable for diverse process control applications. Its robust design guarantees high stability over long-term operation and helps improve overall process efficiency.

---

Product Specifications

---

Applications

• Industrial Process Control: Accurately measures temperature in process control systems for chemical, pharmaceutical, and manufacturing industries.

• Energy Monitoring: Monitors temperature profiles in energy generation and distribution systems to ensure operational safety.

• Automation Systems: Integrates seamlessly with SLC-500 programmable controllers to provide precise analog RTD readings.

• HVAC Systems: Used in building management systems for accurate temperature monitoring in heating, ventilation, and air conditioning.

• Machine Monitoring: Enables predictive maintenance by continuously monitoring critical machine temperatures.

---

Advantages

• High Accuracy: Supports multiple RTD types, ensuring precise and reliable temperature measurements.

• Compact Design: Small footprint allows for easy installation in existing racks without consuming excessive space.

• Robust Operation: Designed to operate reliably in harsh industrial environments with wide operating and storage temperature ranges.

• Easy Integration: Fully compatible with SLC-500 systems, facilitating smooth installation and communication.

• Multi-Channel Support: 8 independent RTD channels reduce the need for multiple modules and simplify wiring.

• Low Power Consumption: Operates efficiently at 24 VDC and 5 VDC with minimal current draw.

FAQ

1. What RTD types are supported by the 1746-NR8 module?
   The module supports standard RTD types including Pt100 and Pt1000, allowing for 2-, 3-, and 4-wire configurations.

2. Can the 1746-NR8 module handle different RTD wiring configurations simultaneously?
   Yes, each of the 8 channels can be individually configured for 2-, 3-, or 4-wire RTD connections.

3. What is the maximum resistance the module can measure?
   The module can accurately measure resistance values corresponding to typical RTD ranges (up to ~400 ohms), depending on the RTD type.

4. Is isolation provided between channels?
   Yes, the module provides channel-to-channel isolation to prevent cross-talk and maintain signal integrity.

5. How does the module handle noisy industrial environments?
   The 1746-NR8 is designed with noise suppression and filtering to ensure stable readings in electrically noisy environments.

6. What is the response time of the module for RTD measurements?
   The module provides rapid response for all 8 channels, ensuring timely temperature data for control systems.

7. Can the module be hot-swapped in an SLC-500 rack?
   No, the 1746-NR8 must be powered down during insertion or removal to prevent potential damage.

8. What communication method does the module use with the SLC-500 controller?
   It uses the standard SLC-500 backplane data bus for communication with the controller.

9. Is there any calibration required for long-term accuracy?
   Periodic verification is recommended, but the module maintains stable calibration over extended operation.

10. Does the module support expansion with additional analog input modules?
    Yes, multiple 1746-NR8 modules can be installed in the same SLC-500 rack, allowing expansion of analog input channels.
