Allen Bradley 1746-OA8 AC Output Module

Product Introduction

The Allen-Bradley 1746-OA8 is an AC output module designed for the SLC 500 programmable controller platform. It provides reliable control of AC-powered field devices in industrial automation systems where robust switching performance and electrical isolation are required.

This module offers eight independent AC output channels, operating in a current sourcing configuration, making it suitable for driving loads such as contactors, solenoid valves, indicator lamps, and alarms. Each channel is designed to switch AC loads within a wide voltage range, allowing flexible integration into different industrial power environments.

Engineered for dependable operation in control cabinets, the 1746-OA8 emphasizes electrical robustness, predictable switching behavior, and seamless compatibility with SLC 500 processors. It is commonly used in legacy systems, retrofit projects, and standard machine control applications where AC outputs remain the preferred choice for field actuation.

---

Product Specifications

---

Applications

• Industrial machine control, switching AC contactors, relays, and pilot devices

• Process automation systems, controlling AC-powered actuators and indicators

• Material handling equipment, driving warning lights, alarms, and auxiliary devices

• Manufacturing production lines, providing reliable AC output control for field devices

• Utility and infrastructure systems, managing AC loads in monitoring and control panels

• Legacy SLC 500 installations, maintaining AC output capability without system redesign

---

Advantages

• Wide AC voltage range, allowing use across different industrial power standards

• Eight-channel density, reducing the number of modules required in the I/O chassis

• Solid-state switching, improving reliability and reducing mechanical wear

• Electrical isolation, protecting the controller from field-side disturbances

• Current sourcing design, suitable for standard AC load wiring practices

• Seamless SLC 500 integration, ensuring straightforward configuration and operation

• Stable long-term performance, supporting continuous industrial duty cycles

FAQ

1. What types of loads can be driven by the 1746-OA8 module?
   The module is designed to drive AC loads such as contactors, solenoids, indicator lamps, and alarms.

2. What does current sourcing mean in this module?
   Current sourcing indicates that the module supplies current to the load when the output is energized.

3. Is the module suitable for inductive loads?
   Yes, it can be used with inductive AC loads when proper system design practices are followed.

4. How are outputs controlled by the SLC 500 processor?
   Each output channel is individually controlled through the processor’s output image table.

5. Does the module provide electrical isolation?
   Yes, output-to-backplane isolation is built in to protect the controller and system electronics.

6. Can outputs be switched independently?
   All eight output channels can be controlled independently based on application logic.

7. Is the module designed for continuous operation?
   The 1746-OA8 is intended for continuous industrial operation within a control cabinet.

8. How does the module handle AC voltage variations?
   It is designed to operate reliably within its specified wide AC voltage range.

9. Does the module require external power supplies?
   No additional power supplies are required beyond the AC load power and system backplane power.

10. Can the module be replaced without changing the control program?
    In most cases, the module can be replaced directly without modifying the existing control logic.
