Product Introduction
The Allen-Bradley 1761-L20BWA-5A is a MicroLogix 1000 programmable controller designed for versatile standalone automation and OEM applications. Operating on 120/240 VAC, it features 12 DC digital inputs, 4 analog inputs, 1 analog output, and 8 relay outputs, enabling precise monitoring and control of both digital and analog signals in small-scale industrial processes.
With its robust AC-powered design, the 1761-L20BWA-5A is ideal for process control, motor control, alarm management, and signal acquisition tasks. Its compact size allows seamless integration into panel-mounted control systems for machinery and OEM equipment requiring mixed I/O functionality.
Product Specifications
| Parameter | Description |
|---|---|
| Model Number | 1761-L20BWA-5A |
| Product Series | MicroLogix 1000 |
| Controller Type | Compact PLC |
| Power Supply | 120/240 VAC |
| Digital Inputs | 12 × 24 VDC |
| Analog Inputs | 4 Channels |
| Analog Outputs | 1 Channel |
| Outputs | 8 × Relay Outputs |
| User Memory | 8 KB EEPROM |
| Communication Port | RS-232 Serial Port |
| Programming Software | RSLogix 500 |
| Mounting Type | DIN Rail / Panel Mount |
| Dimensions | 200 × 73 × 80 mm |
| Weight | 0.249 kg |
Applications
● Standalone machine automation with mixed digital and analog I/O requirements.
● Process monitoring and control for small-scale industrial equipment.
● Motor and actuator control using relay outputs.
● Signal acquisition and alarm systems.
● OEM panel integration requiring AC-powered operation.
● Small production and packaging systems needing precise control.
Advantages
● Mixed I/O support with digital, analog inputs, and analog output channels.
● AC-powered operation compatible with 120/240 VAC environments.
● Multiple relay outputs for controlling motors, solenoids, or other AC/DC devices.
● 8 KB EEPROM memory enables complex logic programming.
● Compact design fits into panel-mounted control systems.
● Reliable and programmable via RSLogix 500 for small automation applications.
