Allen Bradley 1769-PB4 CompactLogix Compact I/O Power Supply

Product Introduction

The Allen Bradley 1769-PB4 CompactLogix Compact I/O Power Supply is a DC-powered module designed to provide robust and reliable power for CompactLogix controllers and connected I/O modules. It ensures stable operation of industrial automation systems by delivering 24 VDC output to multiple I/O modules while supporting higher current demands.

The module operates on a 19.2–31.2 VDC input voltage range, delivering up to 14.5 W output power and a current rating of 30 A, making it suitable for larger CompactLogix I/O configurations or systems with higher load requirements. Its efficient and compact design allows integration into industrial control panels without taking up excessive space.

The 1769-PB4 is widely used in machine automation, process control systems, and OEM equipment where reliable DC power distribution is essential for stable system performance.

---

Product Specifications

---

Applications

• CompactLogix automation systems
Supplies stable DC power to controllers and connected I/O modules for reliable operation.

• Industrial machine control
Used in panels powering high-load automation devices and multiple I/O modules.

• Process automation systems
Provides consistent power for distributed I/O controlling actuators, sensors, and other devices.

• Factory and production lines
Supports large-scale automation configurations requiring higher current capacity.

• OEM automation machinery
Used in custom-built machines where multiple I/O modules demand reliable DC power.

---

Advantages

• High current capacity
Supports up to 30 A, allowing operation of multiple I/O modules simultaneously.

• Stable 24 VDC output
Ensures reliable system performance for connected modules and devices.

• Wide DC input range
Operates with 19.2–31.2 VDC, providing flexibility for industrial power environments.

• Compact and efficient design
Optimized for installation in control panels while delivering high output power.

• Seamless system integration
Fully compatible with the 1769 CompactLogix I/O platform for scalable automation setups.

FAQ

1. What is the primary purpose of the 1769-PB4 module?
   It provides stable DC power to CompactLogix controllers and connected I/O modules to ensure reliable operation of automation systems.

2. What input voltage range does the module support?
   The module operates on DC voltages between 19.2 and 31.2 VDC.

3. What is the output voltage of the power supply?
   It delivers a regulated 24 VDC output suitable for Compact I/O modules.

4. What is the maximum output power of the module?
   The power supply can deliver up to 14.5 W of output power.

5. What is the current rating of the module?
   The module supports a current rating of 30 A, sufficient for multiple I/O modules or higher load applications.

6. Can the 1769-PB4 support large I/O configurations?
   Yes, its high current capacity allows power to multiple modules in larger CompactLogix systems.

7. Is the module suitable for machine automation systems?
   Yes, it is commonly used in industrial machines, production lines, and process automation.

8. How does the module ensure system reliability?
   It provides stable and regulated DC power to connected modules, preventing voltage fluctuations that could disrupt operation.

9. Can this module be integrated with other 1769 series modules?
   Yes, it is fully compatible with other CompactLogix I/O modules for flexible system expansion.

10. What advantages does the 1769-PB4 offer over smaller power supplies?
    It supports higher loads and more I/O modules, ensuring consistent operation in demanding automation environments.
