Allen Bradley 1783-NATR Network Address Translation Router

Product Introduction

The Allen-Bradley 1783-NATR Network Address Translation Router is an industrial-grade NAT (Network Address Translation) router designed to provide secure and flexible networking for EtherNet/IP and industrial automation systems. It belongs to the Allen-Bradley Stratix Industrial Networking Portfolio, offering network segmentation, address translation, and support for Device Level Ring (DLR) topologies.

The 1783-NATR router enables 1:1 NAT with up to 32 translation mappings, allowing devices in different subnets to communicate securely without IP conflicts. It supports both linear and DLR network architectures, providing flexible integration into complex industrial automation networks. Configuration can be performed via web interface or EDS/AOP tools, and an SD card is available for configuration storage and firmware updates.

This device is commonly deployed in industrial control cabinets, machine automation systems, and plant-level EtherNet/IP networks, ensuring secure communication between devices while maintaining network resilience and scalability.

---

Product Specifications

---

Applications

• Industrial network segmentation
Separates subnets and provides secure communication between devices in different network zones.

• Device Level Ring (DLR) integration
Supports DLR topologies for network redundancy and fast fault recovery.

• EtherNet/IP routing
Enables communication between EtherNet/IP devices across different subnets.

• Industrial control cabinets
Installed in panels to manage network traffic and IP address translation.

• Automation system connectivity
Connects PLCs, HMIs, drives, and other networked automation devices while maintaining network integrity.

---

Advantages

• 1:1 NAT with multiple mappings
Supports up to 32 translation mappings for secure industrial network operation.

• Flexible topology support
Works with linear and DLR networks, ensuring adaptability in complex automation systems.

• Configurable via web or EDS/AOP
Simplifies setup and management of network configurations.

• SD card support
Allows storage of configuration files and firmware updates.

• Compact DIN rail mounting
Easy integration into industrial control cabinets.

• Reliable industrial networking
Provides secure and robust communication for automation systems.

FAQ

1. What is the main function of the 1783-NATR?
   It is a NAT router that allows devices in different subnets to communicate securely within industrial networks.

2. How many NAT translation mappings are supported?
   The device supports up to 32 1:1 NAT translation mappings.

3. Which network topologies are supported?
   It supports linear and Device Level Ring (DLR) network topologies.

4. How is the router configured?
   Configuration can be done via a web interface or EDS/AOP tools.

5. Does the device support SD cards?
   Yes, for storing configuration files and firmware updates.

6. Can it be used in EtherNet/IP networks?
   Yes, it is designed for EtherNet/IP industrial networks.

7. Is the router suitable for installation in control cabinets?
   Yes, it supports DIN rail mounting for compact panel installation.

8. What devices can be connected through this router?
   PLCs, HMIs, drives, and other EtherNet/IP-enabled industrial devices.

9. How does the NATR improve network security?
   By translating addresses, it prevents IP conflicts and segments networks for safe communication.

10. Can it support network redundancy?
    Yes, it works with DLR topologies for fast network recovery in case of faults.
