Allen Bradley 1794-ACN Flex I/O ControlNet Adapter Module

Product Introduction

The Allen-Bradley 1794-ACN Flex I/O ControlNet Adapter Module is a high-performance communication interface that connects Flex I/O modules to a ControlNet network. It serves as a bridge between the I/O scanner port and distributed I/O devices, allowing centralized controllers to monitor and control remote I/O efficiently.

This adapter integrates a built-in power supply, converting 24 VDC nominal supply to 5 VDC for the Flex I/O backplane, supporting a maximum output current of 640 mA. It supports up to 8 Flex I/O modules per adapter, facilitating scalable system design. With a ControlNet communication rate of 5 Mbps and an isolation voltage of 850 VDC, it ensures robust signal integrity and network reliability even in industrial environments.

Compact, lightweight, and easy to install, the 1794-ACN is ideal for distributed automation applications requiring fast and secure communication between controllers and remote I/O devices.

---

Product Specifications

---

Applications

• Distributed I/O systems – Connects Flex I/O modules to ControlNet networks for centralized monitoring and control

• Factory automation – Supports integration of remote I/O modules in assembly, packaging, and material handling systems

• Industrial process control – Provides fast and reliable communication between controllers and remote field devices

• OEM machinery – Enables scalable control architecture for machine builders

• Remote monitoring and diagnostics – Allows operators to monitor distributed I/O modules in real-time over ControlNet

---

Advantages

• Integrated power supply – Converts 24 VDC to 5 VDC to power the Flex I/O backplane efficiently

• Supports up to 8 I/O modules – Facilitates scalable and modular system designs

• High-speed communication – 5 Mbps ControlNet interface ensures fast and reliable data transfer

• Electrical isolation – 850 VDC isolation voltage protects the network and connected devices

• Compact and lightweight – 87 x 68 x 69 mm design simplifies installation in panels and enclosures

• Seamless Flex I/O integration – Compatible with all Flex I/O modules for flexible distributed I/O deployment

FAQ

1. What is the maximum number of I/O modules supported?
   The adapter supports up to 8 Flex I/O modules.

2. What type of network does this adapter connect to?
   It connects Flex I/O modules to a ControlNet network.

3. What is the communication rate of the adapter?
   The module supports a 5 Mbps ControlNet communication rate.

4. What is the purpose of the built-in power supply?
   It converts 24 VDC input to 5 VDC to power the Flex I/O backplane modules.

5. What is the maximum FlexBus output current?
   The FlexBus output current is 640 mA max at 5 VDC.

6. What is the isolation voltage of the module?
   It provides 850 VDC isolation between the network and I/O backplane.

7. Can this adapter operate in industrial environments?
   Yes, it is designed for standard industrial operating conditions.

8. How is the adapter mounted?
   It can be mounted on DIN rails or panels.

9. Is this module compatible with all Flex I/O modules?
   Yes, it interfaces with standard Flex I/O modules for distributed control.

10. Does it support diagnostics and monitoring?
    Yes, it allows monitoring of connected Flex I/O modules over ControlNet.
