The Allen-Bradley 1794-IV16 FLEX I/O Digital Source Input Module is a compact and efficient discrete input module designed for reliable signal acquisition in industrial automation systems. As part of the FLEX I/O platform from Rockwell Automation, this module is optimized for distributed I/O architectures requiring stable and cost-effective digital input processing.
The 1794-IV16 features 16 sourcing (PNP) input points operating at a nominal 24 VDC, making it suitable for use with sinking field devices. Its non-isolated design allows for simplified system configuration and reduced cost in applications where isolation is not required. Integrated LED indicators provide clear visual feedback for each input channel, improving troubleshooting and system diagnostics.
With its open-style construction and DIN rail mounting, the module ensures easy installation and dependable operation in industrial control panels.
Product Specifications
| Parameter | Description |
|---|---|
| Model | 1794-IV16 |
| Brand | Allen-Bradley |
| Series | FLEX I/O |
| Module Type | Digital Source Input Module |
| Signal Type | Discrete |
| Input Type | DC Input |
| Number of Inputs | 16 Points |
| Input Configuration | Sourcing (PNP), Non-Isolated |
| Rated Voltage | 24 VDC Nominal |
| Input Current | 11 mA |
| Indicators | LED Status Indicators per channel |
| Mounting Type | DIN Mount |
| Construction | Open Style |
| Protection Rating | IP20 |
| Communication | FLEX I/O Backplane Communication |
| Performance | Stable digital signal acquisition |
| Dimensions | 94 × 46 × 53 mm |
| Weight | 0.09 kg |
Applications
• Industrial Automation Systems – Used for monitoring digital signals from field devices such as push buttons and switches.
• Manufacturing Equipment – Enables real-time detection of machine status signals in production environments.
• Control Panels – Suitable for compact digital input solutions in panel-based automation systems.
• Material Handling Systems – Provides reliable signal acquisition for conveyors and logistics equipment.
• Distributed I/O Architectures – Ideal for remote digital signal collection, improving system flexibility.
Advantages
• Sourcing Input Design – Compatible with sinking field devices, expanding application flexibility.
• Cost-Effective Solution – Non-isolated design reduces cost while maintaining reliable performance.
• Clear Diagnostics – LED indicators provide real-time visual status of each input channel.
• Compact Form Factor – Saves panel space with high-density 16-point input configuration.
• Easy Installation – DIN rail mounting ensures quick setup and maintenance.
• Seamless Integration – Fully compatible with FLEX I/O systems for modular automation architectures.
