Allen Bradley 2094-BC01-M01-M Kinetix 6200/6500 Integrated Axis Module

Product Introduction

The Allen-Bradley 2094-BC01-M01-M Kinetix integrated axis module is a high-performance motion control component designed for use in Kinetix 6200 and Kinetix 6500 servo drive systems. It combines both converter and inverter functionality within a single module, providing a compact and efficient solution for controlling servo motors in demanding industrial applications.

This module operates on a 360/480 VAC input and delivers a 6 kW converter output along with a 3.9 kW inverter output. It is engineered to provide precise motion control, high dynamic response, and stable performance in multi-axis systems. The integrated Safe Torque-Off (STO) feature enhances system safety by removing motor torque without disconnecting power, supporting modern safety requirements in industrial automation.

With its robust construction and integrated design, the 2094-BC01-M01-M simplifies system architecture, reduces wiring complexity, and improves overall system efficiency. It is widely used in applications that require coordinated motion control, high precision, and reliable operation.

---

Product Specifications

---

Applications

• Multi-Axis Motion Systems – Provides synchronized control for coordinated servo axes.

• Packaging Machinery – Ensures precise positioning and high-speed operation in automated lines.

• Material Handling Equipment – Controls conveyors, lifts, and robotic movement systems.

• CNC and Machine Tools – Delivers accurate motion control for cutting and machining processes.

• Automated Assembly Systems – Supports complex motion sequences with high repeatability.

• Industrial Robotics – Enables smooth and responsive servo motor control.

---

Advantages

• Integrated Converter and Inverter – Reduces system complexity and minimizes wiring requirements.

• High Power Performance – Supports demanding motion applications with stable output.

• Safe Torque-Off Function – Enhances machine safety without removing power from the system.

• Compact Design – Optimizes cabinet space while maintaining high performance.

• Reliable Motion Control – Ensures precise and consistent servo operation.

• Efficient System Integration – Designed for seamless use with Kinetix 6200/6500 systems.

• Industrial Durability – Built for continuous operation in demanding environments.

FAQ

1. What is the main function of this module?
   It combines converter and inverter functions to control servo motors in motion systems.
2. What input voltage does this module support?
   It operates on 360 to 480 VAC input power.
3. What is the output power of the converter and inverter?
   The converter provides 6 kW, and the inverter provides 3.9 kW.
4. What is the purpose of the Safe Torque-Off feature?
   It safely removes motor torque without disconnecting power, improving system safety.
5. Is this module suitable for multi-axis systems?
   Yes, it is designed for coordinated multi-axis motion control applications.
6. Can it be used in high-speed automation systems?
   Yes, it provides fast response and precise control for high-speed operations.
7. What types of applications typically use this module?
   It is used in packaging, robotics, CNC machines, and automated assembly systems.
8. Does this module simplify system design?
   Yes, the integrated design reduces wiring and overall system complexity.
9. Is this module compatible with Kinetix 6500 systems?
   Yes, it is fully compatible with both Kinetix 6200 and 6500 platforms.
10. What kind of motors can be controlled with this module?
    It is designed to control servo motors used in industrial motion applications.
