Product Introduction
The Bently Nevada 16710-50 Interconnect Cable is a premium-quality, factory-assembled cable designed specifically for connecting proximity probe systems to monitoring equipment within the Bently Nevada 3300, 3300 XL, and 3500 series. As a critical part of the vibration monitoring and machine protection system, this cable ensures reliable signal integrity between proximity sensors, extension cables, and monitoring modules.
With a standard length of 50 feet (15.24 meters), the 16710-50 model is engineered with robust shielding and durable insulation to resist EMI/RFI interference and physical wear. It features pre-installed connectors on each end, allowing plug-and-play operation with Bently Nevada proximity transducers and monitors. Built to withstand harsh industrial environments, this cable is suitable for use in power generation, petrochemical plants, steel mills, and other heavy industries.
Product Specifications
| Parameter | Description |
|---|---|
| Model Number | 16710-50 |
| Manufacturer | Bently Nevada (A Baker Hughes Company) |
| Cable Type | Interconnect Cable |
| Application | Signal transmission between proximity probes and monitors |
| Compatible Systems | 3300 Series, 3300 XL, 3500 Series |
| Cable Length | 50 feet (15.24 meters) |
| Connector Type | Male and Female connectors (pre-installed) |
| Connector Material | Gold-plated or nickel-plated brass (dependent on version) |
| Shielding | Braided and foil shield for EMI/RFI protection |
| Insulation Material | Flame-retardant thermoplastic |
| Temperature Range | -30°C to +90°C |
| Maximum Voltage Rating | 300 V |
| Color | Typically blue or gray |
| Environmental Rating | Suitable for industrial and outdoor use |
| Standards Compliance | RoHS, CE, UL (as applicable) |
| Weight | 1.2 kg |
Product Applications
The 16710-50 Interconnect Cable is designed for critical connectivity within Bently Nevada’s condition monitoring systems. It plays an essential role in ensuring data integrity between vibration sensors and analysis hardware. Major application sectors include:
-
Power Generation Plants – For turbine and generator vibration analysis
-
Oil & Gas Facilities – Used in compressor, pump, and motor monitoring
-
Petrochemical Refineries – Continuous process machinery vibration tracking
-
Steel and Mining Operations – Harsh-duty use in rugged industrial environments
-
Marine and Offshore Platforms – Reliable in corrosive and high-humidity zones
-
Pharmaceutical and Food Industries – Ensures equipment uptime and reliability
Product Advantages
-
Factory-Assembled Quality: Manufactured and tested under stringent controls to ensure zero-defect signal transmission.
-
High EMI/RFI Shielding: Dual-shielded cable construction mitigates interference from electrical noise.
-
Plug-and-Play Installation: Ready-to-use with Bently Nevada monitoring systems—no on-site termination required.
-
Industrial Durability: Withstands mechanical stress, extreme temperatures, and corrosive environments.
-
Optimized for System Compatibility: Engineered specifically for Bently Nevada’s 3300, 3300 XL, and 3500 systems.
-
Low Signal Attenuation: Maintains accurate transducer signals over long distances.
-
Flexible and Safe: RoHS-compliant insulation with low smoke and flame-retardant properties.
Frequently Asked Questions (FAQ)
-
What is the main function of the Bently Nevada 16710-50 cable?
It connects proximity probes or transducers to monitoring systems, transmitting signals accurately and reliably. -
Which systems are compatible with the 16710-50 cable?
It is compatible with Bently Nevada’s 3300, 3300 XL, and 3500 series monitoring systems. -
Can I cut and terminate the 16710-50 cable manually?
No. It comes factory-terminated to ensure performance and is not designed for field termination. -
What is the standard length of this cable?
The 16710-50 is 50 feet (15.24 meters) in length. -
Is the cable shielded against electromagnetic interference?
Yes, it features both foil and braided shielding for superior EMI/RFI protection. -
What environments is this cable suitable for?
It is designed for industrial environments including power plants, refineries, and offshore rigs. -
What temperature can the cable withstand?
It operates between -30°C to +90°C. -
Does this cable support analog or digital signals?
It is used to transmit analog proximity signals. -
What is the typical diameter of the cable?
The outer diameter is 6.5 mm. -
Is this cable available in other lengths?
Yes, Bently Nevada offers interconnect cables in various lengths, such as 16710-20, 16710-100, etc.
Related Models (Same Series or Application)
| Model | Description | Length | Compatibility |
|---|---|---|---|
| 16710-20 | Interconnect Cable, 20 ft | 20 feet (6.1 m) | 3300/3500 Series |
| 16710-100 | Interconnect Cable, 100 ft | 100 feet (30.5 m) | 3300/3500 Series |
| 330130-040-00 | Extension Cable for Proximitor System | 4.0 meters | 3300 XL |
| 330180-91-05 | Coaxial Cable Assembly, 5 meters | 5 meters | 3300 XL Series |
| 330178-50-00 | Cable Assembly, 50 ft for 7200 system | 50 feet | 7200 Proximity |
| 330101-00-40-10-02-00 | Proximity probe with integral cable | 4.0 meters | 3300 XL |
