Product Introduction:
The Bently Nevada 21747-080-00 Proximitor Probe Extension Cable is designed specifically to extend the reach of Bently Nevada’s proximitor probes. It plays a crucial role in monitoring and measuring the proximity of rotating machinery, ensuring that maintenance teams can detect any potential misalignments or malfunctions before they become critical. This extension cable is durable, offering excellent performance in harsh industrial environments where precision and reliability are key.
This cable connects to the Bently Nevada Proximitor Probe, providing a secure and reliable link to the monitoring system. Its robust construction allows for long-term use and ensures minimal signal loss across the extended distance. This product is particularly useful in cases where the proximitor probe cannot be directly mounted close to the measurement point.
Product Specifications:
| Specification | Details |
|---|---|
| Model Number | 21747-080-00 |
| Cable Length | 8 m |
| Connector Type | 3-pin / 4-pin (dependent on application) |
| Signal Type | Analog (used with Proximitor Probes) |
| Temperature Rating | -40°C to 85°C (-40°F to 185°F) |
| Cable Jacket Material | PVC (Polyvinyl Chloride) |
| Weight | 0.249 kg |
| Outer Diameter | 0.45 inches (11.43 mm) |
| Inner Conductor Material | Tinned Copper |
| Insulation Material | PVC |
| Maximum Voltage | 300 VDC |
| Application | Industrial machinery monitoring |
Product Applications:
The Bently Nevada 21747-080-00 Proximitor Probe Extension Cable is used in various industrial applications where precise machine condition monitoring is essential. Some of the key areas of use include:
-
Rotating Equipment Monitoring: It is commonly used in power plants, refineries, and manufacturing facilities to monitor the proximity of rotating machinery, ensuring that any misalignment, imbalance, or other mechanical issues are detected early.
-
Turbine and Generator Monitoring: The cable is often used in turbine and generator setups, where proximity sensors need to be placed at a distance from the control unit due to physical limitations or safety concerns.
-
Pump and Compressor Systems: The cable is also utilized in pump and compressor systems, where vibration and alignment monitoring are crucial for efficient performance and to avoid unexpected downtime.
-
Automated Control Systems: The extension cable integrates seamlessly with automated monitoring systems, enabling continuous machine health data transmission.
Advantages of the Product:
-
Durability: The Bently Nevada 21747-080-00 is designed to withstand the harsh environments typical in industrial facilities. The high-quality PVC insulation and tough outer jacket offer resistance to oil, moisture, and mechanical wear, ensuring longevity.
-
Extended Reach: This extension cable allows for the placement of proximity probes at a greater distance, making it ideal for systems where probes need to be mounted further away from the measurement point.
-
Minimal Signal Loss: The cable is engineered to minimize signal loss over long distances, ensuring that the data transmitted from the proximitor probe is accurate and reliable.
-
Versatility: With various connector types and an adaptable design, this extension cable can be used with a wide range of Bently Nevada proximitor probes, making it highly versatile for different applications.
-
Temperature Resistance: The cable is rated to perform in extreme temperatures, from -40°C to 85°C, making it suitable for both hot and cold industrial environments.
-
Easy Installation: The cable’s design allows for easy and quick installation, reducing downtime during setup or replacement.
FAQ
1.What is the maximum cable length supported by the Bently Nevada 21747-080-00?
The maximum cable length for this model is 8 m, which is suitable for most industrial monitoring needs.
2.Can the Bently Nevada 21747-080-00 be used with all proximitor probes?
It is specifically designed for use with Bently Nevada proximitor probes. Compatibility should be confirmed based on your probe’s requirements.
3.What materials are used for the insulation and outer jacket?
The insulation is made from PVC, while the outer jacket is also PVC, providing excellent resistance to environmental factors such as moisture and chemicals.
4.What is the voltage rating of the cable?
The Bently Nevada 21747-080-00 extension cable has a maximum voltage rating of 300 VDC.
5.What is the weight of the extension cable?
The cable weighs 0.249 kg.
6.Can this cable be used in hazardous environments?
Yes, the cable is built to withstand harsh industrial conditions, though specific environmental factors should be considered based on your application.
7.What is the operating temperature range for the Bently Nevada 21747-080-00?
The cable operates effectively in temperatures ranging from -40°C to 85°C (-40°F to 185°F).
8.Is there a warranty on the Bently Nevada 21747-080-00?
We provide one year warranty.
9.Can I use the extension cable for high-frequency signals?
Yes, the cable is designed for analog signals typically used with proximitor probes, which work effectively with high-frequency data in monitoring systems.
10.How easy is it to install this cable?
The installation process is straightforward, and the cable is designed for ease of use, with connectors that match the Bently Nevada proximitor probe units.
