The Bently Nevada 26530-12-10-03-018-191-22-04-00 Dual Probe Transducer System is a precision monitoring device engineered for industrial machinery vibration and shaft position measurement. The dual-probe configuration provides redundancy to ensure reliable, continuous operation, making it essential for machinery protection and condition monitoring systems.
This system incorporates two independent probes to deliver accurate measurements of shaft displacement, vibration amplitude, and phase information. It is extensively used in turbines, generators, compressors, pumps, and other high-speed rotating equipment. Designed to operate in harsh industrial environments, the transducer system offers high immunity to electrical noise, temperature fluctuations, and mechanical vibration, ensuring stable and consistent data.
With a 1.0-meter probe lead, the system allows flexible installation and precise alignment, facilitating integration into a variety of machinery monitoring networks. It is fully compatible with Bently Nevada 3300 series monitoring systems, providing high-quality signal output and supporting predictive maintenance strategies to reduce downtime and operational risk.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 26530-12-10-03-018-191-22-04-00 |
| Type | Dual Probe Transducer System |
| Function | Vibration and shaft displacement measurement |
| Number of Probes | 2 |
| Probe Lead Length | 1.0 meter |
| Output Signal | Differential voltage |
| Frequency Response | DC to 10 kHz |
| Operating Temperature | -40°C to +120°C |
| Storage Temperature | -40°C to +125°C |
| Operating Humidity | 0% to 95%, non-condensing |
| Sensitivity | 50 mV/mil nominal (typical, depending on probe configuration) |
| Probe Tip Clearance | 0.25 to 0.5 mm typical |
| Power Supply | 24 V DC typical |
| Power Consumption | 2 W |
| Weight | 3 kg |
| Compliance Standards | ISO, CE, RoHS |
| Environmental Protection | IP65 rated housing for harsh industrial environments |
| Applications | Turbines, generators, compressors, pumps, motors, industrial rotating machinery |
Applications
The 26530-12-10-03-018-191-22-04-00 Dual Probe Transducer System is suitable for:
-
Turbine and generator vibration and shaft displacement monitoring
-
High-speed compressor and pump shaft monitoring
-
Critical industrial motors in petrochemical and power plants
-
Rotating machinery condition monitoring for predictive maintenance
-
Integration with Bently Nevada 3300 series monitoring systems
-
Industrial applications requiring redundancy, high accuracy, and real-time data
Advantages
-
Dual Probe Redundancy: Provides continuous operation and high reliability in critical monitoring applications.
-
High Precision Measurement: Detects small vibration amplitudes and precise shaft displacement.
-
Industrial-Grade Robustness: Resistant to vibration, electrical noise, and extreme temperatures.
-
Flexible Installation: 1.0-meter probe lead allows precise positioning and alignment.
-
Wide Frequency Response: DC to 10 kHz ensures monitoring of slow and fast machine dynamics.
-
Low Power Operation: Consumes only 2 W, minimizing heat generation.
-
Seamless Integration: Compatible with Bently Nevada 3300 series and other monitoring/protection systems.
-
Real-Time Continuous Monitoring: Enables predictive maintenance and machinery protection.
