Product Introduction
The Bently Nevada 330101-00-12-15-02-05 is a high-precision non-contact proximity probe from the 3300 XL 8 mm series, a widely deployed industrial solution for monitoring critical machinery. Built to measure the static and dynamic displacement of rotating shafts, this proximity probe plays a central role in condition monitoring and machinery protection systems.
Manufactured by Bently Nevada, a division of Baker Hughes, the 330101 probe is part of a transducer system that includes an extension cable and Proximitor® sensor. This model is engineered for robust, long-life operation in harsh environments including oil refineries, power plants, petrochemical facilities, and manufacturing.
This specific variant, with a 12 ft probe length and 15 ft cable, offers extended range connectivity, making it suitable for installations where cable routing and environmental shielding are critical.
Product Specifications
| Specification | Details |
|---|---|
| Product Name | 3300 XL 8 mm Proximity Probe |
| Model Number | 330101-00-12-15-02-05 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Probe Tip Diameter | 8 mm |
| Thread Type | 3/8-24 UNF |
| Thread Length | 0.5 inch (12.7 mm) |
| Connector Type | Miniature coaxial connector (to extension cable) |
| Target Material | 4140 steel (API 670 standard) |
| System Sensitivity | 200 mV/mil (7.87 mV/μm) |
| Linear Range | 2 mm (80 mils) |
| Usable Gap Range | 0.25 to 2.25 mm |
| Operating Temperature | -35°C to +177°C |
| Storage Temperature | -51°C to +177°C |
| Environmental Protection | IP68 |
| Compliance Standards | API 670, CE, RoHS |
| Weight | 0.485 kg |
| Total Length | 1.5 meters |
Product Applications
The 330101-00-12-15-02-05 proximity probe is designed for dynamic and static shaft monitoring, making it a vital component in the following applications:
-
Turbomachinery: Vibration and displacement monitoring in gas and steam turbines.
-
Compressors and Pumps: Used for condition-based maintenance and performance optimization.
-
Electric Motors and Generators: Helps identify shaft misalignment or imbalance.
-
Gearboxes: Monitors gear mesh wear and torque-related displacement.
-
Centrifuges and Fans: For rotor condition monitoring and preventive diagnostics.
-
Critical Infrastructure: Any rotating machinery requiring API 670-compliant vibration monitoring.
Product Advantages
-
API 670 Compliant: Engineered to meet global industry standards for machinery protection.
-
Reliable Non-Contact Measurement: Ensures accurate readings without physical wear.
-
Robust Environmental Resistance: IP68 rating protects against water, dust, and oil ingress.
-
Wide Operating Range: Performs in extreme temperatures from -35°C to +177°C.
-
Superior Mechanical Durability: Withstands high vibration and harsh field environments.
-
Flexible Cabling Options: Long probe and cable lengths support remote installations.
-
Extended System Compatibility: Works seamlessly with 3300 XL extension cables and Proximitor sensors.
-
Minimal Drift Over Time: Designed for long-term accuracy and reduced recalibration needs.
-
Industry Proven: Trusted by OEMs and operators worldwide in high-risk operations.
-
Ease of Installation: Compact form factor and standard threading enable fast deployment.
Frequently Asked Questions (FAQ)
-
What does the part number 330101-00-12-15-02-05 specify?
It indicates a 12-inch probe with a 15-foot integral cable and specific connector options. -
Can this probe be used in hazardous environments?
Yes, it is designed for harsh industrial applications and complies with environmental ratings like IP68. -
Is the probe compatible with older Bently Nevada systems?
Yes, it is fully compatible with legacy and current 3300 XL transducer systems. -
What is the tip material of the probe?
The tip is made of durable, non-conductive epoxy suitable for high-precision detection. -
Does the cable require shielding in high-EMI environments?
The cable is already shielded; however, grounding is recommended in high EMI zones. -
What’s the calibration target material?
It is calibrated against 4140 steel as per API 670. -
Is the system affected by oil mist or condensation?
No, the IP68 rating allows it to function reliably in oil-laden and wet atmospheres. -
What is the life expectancy of this probe?
When properly installed, the probe typically functions for several years without failure. -
Can the probe be directly connected to monitoring systems?
No, it must connect to a proximitor via an extension cable for signal conditioning. -
How often should the probe be checked or replaced?
Regular inspection during shutdowns is advisable, but replacement is rare unless damaged.
Related Models (Same Series or Functional Variants)
| Model Number | Description | Cable Length | Probe Length | Thread Length |
|---|---|---|---|---|
| 330101-00-10-10-02-00 | 10 ft cable, 10 in probe | 10 ft | 10 in | 0.5 in |
| 330101-00-05-10-02-05 | 5 ft cable, 10 in probe | 5 ft | 10 in | 0.5 in |
| 330101-00-18-15-02-00 | 18 ft cable, 15 in probe | 18 ft | 15 in | 0.5 in |
| 330101-00-08-08-02-05 | 8 ft cable, 8 in probe | 8 ft | 8 in | 0.5 in |
| 330101-00-12-10-01-CN | 12 in probe, 10 ft cable, China localization | 10 ft | 12 in | 0.5 in |
| 330104-00-05-10-01 | 5 mm probe, 10 ft cable | 10 ft | 5 in | 0.5 in |
Popular Bently Nevada Models
| Model Number | Description | Application | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| 3500/22M | Transient Data Interface Module | System communication | 120 × 30 × 140 | 0.45 |
| 3500/42M | Proximitor Monitor | Shaft vibration and position | 100 × 30 × 130 | 0.50 |
| 330130-040-00-00 | 4-meter Extension Cable | Signal extension for probes | 4000 × 5 × 5 | 0.25 |
| 330180-91-05 | Proximitor Sensor | Signal conversion from probes | 70 × 60 × 25 | 0.30 |
| 7200-06-05-03-00 | Driver for Proximity Transducers | Signal conditioning | 80 × 40 × 30 | 0.40 |
| 3300 XL 5 mm Probe | Compact 5 mm probe for tight installations | Limited space vibration monitoring | 60 × 5 × 5 | 0.20 |
