Product Overview
The Bently Nevada 330101-00-16-05-02-05 is a member of the trusted 3300 XL 8 mm Proximity Transducer System, designed for accurate, non-contact measurement of static and dynamic motion in rotating machinery. It forms part of a system comprising a proximity probe, extension cable, and Proximitor® sensor, specifically engineered for continuous monitoring of shaft vibration, axial position, and rotor dynamics.
This model features a 16 ft (4.9 m) total system length, consisting of a 5 ft (1.5 m) proximity probe and an 11 ft (3.4 m) extension cable, offering optimal flexibility in installations where sensor placement and cabling paths must be tailored to machinery configuration.
Key Features
-
8 mm probe tip for general-purpose and critical vibration monitoring
-
Total system length of 16 ft: 5 ft probe + 11 ft extension cable
-
Threaded stainless steel body with PEEK sensing tip for chemical resistance
-
High linearity and precision compliant with API 670 standards
-
Resistant to electromagnetic and radio-frequency interference
-
Compatible with 3300 XL Proximitor sensors
-
Designed for rugged industrial environments including turbines, compressors, and motors
-
IP67 rated for environmental sealing
-
Excellent long-term stability and repeatability
Technical Specifications
| Parameter | Specification |
|---|---|
| Probe Tip Diameter | 8 mm |
| Probe Length | 5 ft (1.5 m) |
| Extension Cable Length | 11 ft (3.4 m) |
| Total System Length | 16 ft (4.9 m) |
| Thread Size | 3/8-24 UNF |
| Connector Type | Coaxial connector with gold-plated contacts |
| Sensitivity | 7.87 mV/μm (200 mV/mil) |
| Linearity | ±0.25% full-scale typical |
| Measurement Range | 2 mm (80 mils) nominal |
| Frequency Response | DC to 10 kHz |
| Operating Temperature | -35°C to +177°C (Probe and Extension Cable) |
| Environmental Rating | IP67 |
| Compliance Standards | API 670, CE, RoHS, ATEX/IECEx (depending on configuration) |
| Materials | Probe: Stainless Steel; Tip: PEEK; Cable Jacket: Polyurethane |
| Dimensions | Total Length : 0.5 meter |
| Weight | 0.161 kg |
Product Advantages
-
Precise Condition Monitoring: Delivers accurate real-time data for shaft vibration and position analysis.
-
Flexible Configuration: Mixed probe and cable lengths accommodate complex equipment layouts.
-
High Durability: Engineered for extreme temperatures, moisture, oil, and vibration.
-
Compliance Ready: Adheres to API 670 requirements for safety and performance assurance.
-
Simplified Integration: Compatible with all 3300 XL Proximitor Sensors and Bently Nevada 3500 monitoring systems.
-
Enhanced Uptime: Aids in detecting mechanical issues before failure, reducing maintenance costs and downtime.
-
Reliable in Harsh Environments: Maintains performance in areas with high EMI, oil exposure, and thermal variation.
Industry Applications
-
Steam and Gas Turbines – Shaft vibration, axial thrust, and radial position detection
-
Compressors and Pumps – Monitor dynamic shaft behavior to prevent catastrophic failure
-
Generators and Motors – Identify imbalance, misalignment, or looseness
-
Gearboxes – Track gear mesh conditions and bearing wear
-
Oil & Gas Refineries – Continuous machine health monitoring in hazardous environments
-
Power Generation – Part of critical monitoring systems in base-load and peaking power plants
-
Heavy Machinery – For condition-based maintenance strategies in industrial plants
Frequently Asked Questions (FAQ)
-
What does the model number 330101-00-16-05-02-05 represent?
It designates a proximity probe system with a total length of 16 ft (5 ft probe + 11 ft extension), with specific connector and thread type. -
Can this probe be used in explosive atmospheres?
Certain versions with ATEX/IECEx certifications are suitable for hazardous zones. -
What sensor should I pair with this probe?
It is compatible with Bently Nevada 3300 XL Proximitor Sensors for accurate system response. -
Does this probe meet API 670 standards?
Yes, it complies fully with API 670 performance and reliability criteria. -
What cable materials are used?
The extension cable uses a polyurethane jacket for superior abrasion and chemical resistance. -
Is it suitable for high-temperature equipment?
Yes, it supports operating temperatures up to 177°C. -
What vibration range does it measure?
The system measures dynamic motion within a 2 mm (80 mils) range with ±0.25% accuracy. -
Can I cut or shorten the cable length on-site?
No. The total system length is factory-calibrated and must remain unchanged to ensure accuracy. -
Does the probe require periodic calibration?
No field calibration is needed, but it is recommended to follow standard maintenance checks. -
What maintenance does this product require?
Routine inspection for physical damage and secure connections is typically sufficient.
Related Models in the 3300 XL 8 mm Series
| Model | Description |
|---|---|
| 330101-00-14-10-10-02-05 | 14 ft total: 10 ft probe + 4 ft extension |
| 330101-00-14-10-00-02-05 | 14 ft total: 10 ft probe + 4 ft extension (alternate config) |
| 330104-00-12-10-02-00 | Standard probe with 12 ft probe length |
| 330130-045-00-00 | 45 ft Extension Cable for 3300 XL systems |
| 330180-91-00 | 3300 XL Proximitor Sensor for 8 mm probes |
| 330105-02-12-10-02-00 | High-temperature version of the 3300 XL 8 mm probe |
Popular Bently Nevada Models (Same Brand)
| Model | Description |
|---|---|
| 3500/22M | Transient Data Interface Module |
| 3500/42M | Vibration Monitoring Module |
| 3500/15-05-05-00 | AC Power Supply Module |
| 330104-00-03-05-02-00 | Short proximity probe with 3 ft probe and 5 ft extension |
| 330180-90-00 | Standard Proximitor Sensor |
| 330130-040-00-00 | 40 ft XL Extension Cable |
