Product Introduction
The Bently Nevada 330101-00-20-05-02-05 is a premium-grade proximity probe from the 3300 XL 8mm series, engineered for precise non-contact measurement of shaft displacement and vibration in rotating machinery. This probe is a critical component in predictive maintenance and condition monitoring systems, delivering accurate real-time data to prevent equipment failures and optimize performance.
Designed for compatibility with Bently Nevada’s monitoring systems, the 3300 XL 8mm proximity probe offers robust performance in harsh industrial environments. Its stainless steel construction ensures durability, while its advanced sensing capabilities provide reliable measurements essential for machinery protection.
Product Specifications
| Parameter | Details |
|---|---|
| Model Number | 330101-00-20-05-02-05 |
| Series | 3300 XL 8mm Proximity Probe |
| Thread Size | 3/8-24 UNF |
| Total Length | 0.5 meter |
| Cable Type | Non-armored flexible cable |
| Measuring Range | 80 mils (2.0 mm) |
| Sensitivity | 7.87 mV/mil (200 mV/mm) |
| Operating Temperature | -35°C to +177°C (-31°F to +350°F) |
| Storage Temperature | -40°C to +80°C (-40°F to +176°F) |
| Signal Output | Analog displacement output |
| Housing Material | Stainless steel |
| Connector Type | 3-socket connector |
| Vibration Resistance | Suitable for high-vibration environments |
| Weight | 0.162 kg |
Applications
The 330101-00-20-05-02-05 proximity probe is utilized across various industries for machinery monitoring and protection:
-
Power Generation: Monitoring turbines and generators to detect shaft vibration and displacement.
-
Oil and Gas: Ensuring the integrity of compressors and pumps by detecting early signs of mechanical issues.
-
Manufacturing: Maintaining the performance of rotating equipment such as motors and gearboxes.
-
Petrochemical: Monitoring critical rotating machinery to prevent unscheduled downtimes.
-
Aerospace: Testing and monitoring of engines and other rotating components.
Advantages
-
High Precision: Delivers accurate measurements of shaft displacement and vibration, essential for predictive maintenance.
-
Robust Construction: Stainless steel housing provides durability in harsh industrial environments.
-
Wide Temperature Range: Operates effectively across a broad temperature spectrum, suitable for various applications.
-
Easy Integration: Compatible with Bently Nevada monitoring systems, facilitating seamless integration.
-
Flexible Installation: Non-armored flexible cable allows for versatile routing and installation.
-
Reliable Performance: Designed to withstand high-vibration environments without compromising accuracy.
Frequently Asked Questions (FAQ)
-
What is the primary function of the 330101-00-20-05-02-05 proximity probe?
It measures shaft displacement and vibration in rotating machinery for condition monitoring and protection purposes.
-
Is this probe compatible with all Bently Nevada monitoring systems?
Yes, it is designed for seamless integration with Bently Nevada’s 3300 and 3500 series monitoring systems.
-
Can the probe operate in high-temperature environments?
Yes, it operates effectively within a temperature range of -35°C to +177°C.
-
What is the measuring range of this probe?
It has a measuring range of 80 mils (2.0 mm), suitable for various industrial applications.
-
Does the probe come with an armored cable option?
This specific model comes with a non-armored flexible cable; however, armored versions are available in the 3300 XL series.
-
What is the sensitivity of the probe?
The probe has a sensitivity of 7.87 mV/mil (200 mV/mm), providing precise measurements.
-
Is the probe suitable for use in hazardous environments?
While the probe is robust, suitability for hazardous environments depends on specific certifications; consult the manufacturer for details.
-
What type of connector does the probe use?
It utilizes a 3-socket connector for reliable connections to monitoring systems.
-
Can the probe be used in applications with high vibration?
Yes, it is designed to maintain accuracy in high-vibration environments.
-
What is the weight of the probe?
The probe weighs 0.162 kg, facilitating easy installation.
Related Models (Same Series or Related Models)
| Model Number | Description | Cable Length | Thread Size | Weight |
|---|---|---|---|---|
| 330101-00-16-10-02-00 | 3300 XL 8mm Proximity Probe | 16 feet | 3/8-24 UNF | 0.131 kg |
| 330101-00-24-10-02-05 | 3300 XL 8mm Proximity Probe | 24 feet | 3/8-24 UNF | 0.131 kg |
| 330101-00-25-10-02-00 | 3300 XL 8mm Proximity Probe | 25 feet | 3/8-24 UNF | 0.131 kg |
| 330101-00-30-10-02-05 | 3300 XL 8mm Proximity Probe | 30 feet | 3/8-24 UNF | 0.131 kg |
| 330103-00-20-10-02-00 | 3300 XL 8mm Proximity Probe with M10 Thread | 20 feet | M10 x 1 | 0.131 kg |
| 330876-03-10-00-00 | 3300 XL 50mm Proximity Probe | 10 feet | 3/8-24 UNF | 0.131 kg |
