Product Introduction
The Bently Nevada 330101-00-30-50-02-00 is a high-precision 8mm proximity probe designed for the 3300 XL monitoring system, a globally trusted platform for vibration and shaft position monitoring. This probe serves as a critical component in machinery condition monitoring, providing accurate, real-time data essential for predictive maintenance and fault diagnosis.
Engineered with robust materials and advanced sensing technology, the 8mm probe is ideal for challenging industrial environments such as power generation, oil and gas, and heavy manufacturing. Its compact design allows for installation in tight spaces without sacrificing performance or reliability.
By enabling precise shaft displacement measurements, the probe contributes significantly to safeguarding rotating equipment, reducing unplanned downtime, and optimizing operational efficiency.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | 330101-00-30-50-02-00 |
| Probe Tip Diameter | 8 mm |
| Total Length | 5 meters |
| Operating Temperature | -40°C to +120°C |
| Weight | 1.615 kg |
| Output Signal Type | AC Voltage output proportional to gap |
| Sensing Range | 2 to 8 mm |
| Connector Type | MIL-C-26482 / 4-pin connector |
| Compatible System | Bently Nevada 3300 XL |
| Material | Stainless steel probe tip and body |
| Cable Insulation | Teflon® |
| Compliance | CE, RoHS certified |
Product Applications
Bently Nevada 330101-00-30-50-02-00 proximity probes are widely used in industries where rotating machinery condition is critical. Common applications include:
-
Monitoring vibration and shaft displacement in turbines, compressors, and pumps.
-
Condition monitoring in power plants to detect shaft misalignment or imbalance.
-
Oil and gas installations requiring high reliability in harsh environments.
-
Heavy industrial machinery including motors and generators.
-
Industrial automation systems that require precise real-time feedback on rotating components.
-
Predictive maintenance programs to extend machinery life and prevent catastrophic failure.
These probes are vital components for any asset management strategy focused on maximizing equipment uptime and reducing operational risks.
Product Advantages
-
High Accuracy: Provides precise measurement of shaft position with excellent repeatability.
-
Robust Construction: Stainless steel probe body and tip resist corrosion and mechanical wear.
-
Wide Temperature Range: Operates reliably in extreme temperature conditions from -40°C to +120°C.
-
Compact Size: Small 8mm diameter allows installation in confined spaces without interfering with machinery.
-
Compatibility: Fully compatible with the industry-standard Bently Nevada 3300 XL monitoring system.
-
Reliable Signal Output: AC voltage output directly proportional to gap, facilitating easy integration with monitoring systems.
-
Long Cable Options: Standard cable length with custom lengths available to suit installation needs.
-
Easy Installation: Standard connector and mounting options ensure straightforward setup.
-
Proven Technology: Trusted by industries worldwide for decades.
-
Enhanced Machine Protection: Helps detect early signs of mechanical problems, reducing unplanned outages.
Frequently Asked Questions (FAQ)
-
What is the sensing range of this proximity probe?
The probe measures displacement accurately within a 2 to 8 mm range. -
Is the probe compatible with other monitoring systems besides Bently Nevada 3300 XL?
It is primarily designed for the 3300 XL system, but may work with other systems that accept AC voltage output with similar specifications. -
What type of connector does the probe use?
It uses a military-standard MIL-C-26482 4-pin connector for secure and reliable connections. -
Can the cable length be customized?
Yes, while the standard cable length 5 meters, custom lengths can be ordered depending on installation requirements. -
What environmental conditions can the probe withstand?
It operates reliably between -40°C and +120°C and is designed to resist corrosion and mechanical stress. -
How do I know if the probe is functioning correctly?
Regular system diagnostics in the 3300 XL monitoring unit will indicate probe health; additionally, consistent output signals confirm proper operation. -
Is this probe suitable for outdoor installations?
Yes, with proper enclosure and protection, it can be used outdoors in industrial environments. -
What maintenance is required for the probe?
The probe requires minimal maintenance; periodic inspection for physical damage and cleaning of the probe tip is recommended. -
How is the probe installed on the machinery?
The probe is mounted using a secure threaded fitting close to the shaft, with the cable connected to the monitoring system. -
Where can I purchase genuine Bently Nevada proximity probes?
Contact us.
Recommended Related Models
| Model Number | Description | Probe Diameter (mm) | Cable Length (m) | Notes |
|---|---|---|---|---|
| 330101-00-30-50-01-00 | 5mm Proximity Probe for 3300 XL | 5 | 3 | Compact design |
| 330101-00-30-50-04-00 | 12mm Proximity Probe for 3300 XL | 12 | 3 | Larger sensing tip |
| 330101-00-30-50-10-00 | 8mm Proximity Probe with longer cable | 8 | 10 | Extended cable length |
| 330101-00-30-50-02-01 | 8mm Proximity Probe with armored cable | 8 | 3 | Enhanced mechanical protection |
| 330101-00-30-50-05-00 | 6mm Proximity Probe for 3300 XL | 6 | 3 | Intermediate size |
| 330101-00-30-50-08-00 | 10mm Proximity Probe for 3300 XL | 10 | 3 | Medium diameter tip |
