Product Introduction
The Bently Nevada 330101-00-96-20-02 3300 XL 8mm Proximity Probe is a premium-grade industrial sensing solution designed to ensure accurate shaft vibration and position measurements in rotating machinery. As part of the renowned 3300 XL series, this probe is widely used for critical machinery protection systems in industries such as power generation, oil and gas, petrochemical, and heavy manufacturing. It offers exceptional reliability, long-term stability, and compatibility with a wide range of Bently Nevada monitoring systems, making it an ideal choice for demanding operational environments.
This model features a high-quality 8mm tip with robust construction to withstand harsh industrial conditions. With a total cable length of 2 meters, it provides flexibility for installation across various machinery configurations. Engineered with advanced insulation and shielding, the probe minimizes signal interference and ensures precise, real-time data transmission for machinery health monitoring.
Product Parameters
| Parameter | Specification |
|---|---|
| Product Model | Bently Nevada 330101-00-96-20-02 |
| Series | 3300 XL |
| Probe Tip Diameter | 8 mm |
| System Compatibility | Compatible with 3300 XL Proximity Transducer System |
| Cable Type | Integral coaxial cable with protective insulation |
| Total Length | 2 meters |
| Thread Size | M10 x 1 |
| Operating Temperature | -35°C to +177°C |
| Linear Range | 2 mm (80 mils) |
| Nominal Gap | 2.0 mm |
| Sensitivity | 200 mV/mil ±5% |
| Electrical Isolation | Fully isolated from ground |
| Enclosure Protection | IP66 |
| Compliance Standards | API 670, CE, RoHS |
| Weight | 0.646 kg |
Product Applications
The 330101-00-96-20-02 Proximity Probe plays a critical role in monitoring and protecting machinery assets in high-value industrial applications.
Key application areas include:
-
Turbomachinery: For detecting shaft vibration, position, and dynamic behavior.
-
Compressors and Pumps: Ensures operational reliability by preventing bearing failures.
-
Generators and Motors: Monitors rotor alignment and prevents catastrophic failures.
-
Oil & Gas Processing Plants: Provides real-time machine condition monitoring for safety-critical environments.
-
Petrochemical and Refining Plants: Prevents unplanned downtime through predictive maintenance systems.
Product Advantages
-
High Accuracy and Stability: Maintains consistent performance under extreme temperature and pressure conditions.
-
Wide Compatibility: Designed to integrate seamlessly with the Bently Nevada 3300 XL monitoring system and associated hardware.
-
Durable Construction: Built with corrosion-resistant materials to withstand harsh industrial environments.
-
Extended Cable Length: 2-meter cable provides installation flexibility for complex machinery setups.
-
Noise Immunity: Advanced shielding ensures reliable signal transmission, minimizing the effects of electrical interference.
-
Global Standard Compliance: Meets API 670 and other international standards for machine protection.
Frequently Asked Questions (FAQ)
1. What is the linear range of the 330101-00-96-20-02 probe?
The probe provides a linear measurement range of approximately 2 mm (80 mils), ensuring accurate shaft position and vibration data.
2. Which monitoring systems are compatible with this probe?
It is fully compatible with the Bently Nevada 3300 XL Proximity Transducer System and other systems designed for 8mm probes.
3. How is electrical isolation achieved in this probe?
The probe incorporates full ground isolation, preventing electrical interference and ensuring accurate signal integrity in noisy industrial environments.
4. What sensitivity does this probe provide?
It delivers a sensitivity of 200 mV/mil (7.87 mV/µm) ±5%, which is standard for the 3300 XL 8mm probe series.
5. What is the nominal gap setting for installation?
The recommended nominal gap is 2.0 mm (80 mils), which ensures accurate displacement measurement.
6. Can the probe withstand high-temperature environments?
Yes, it operates reliably within a temperature range of -35°C to +177°C, making it suitable for harsh industrial conditions.
7. Is the probe compliant with API 670 standards?
Yes, the 330101-00-96-20-02 meets API 670 standards for machinery protection systems.
8. How is cable shielding implemented in this model?
The probe uses a coaxial cable with advanced insulation and shielding to minimize electromagnetic interference and improve signal quality.
9. What is the function of the IP66 enclosure rating?
The IP66 rating ensures the probe is fully protected against dust and high-pressure water, ideal for outdoor and rugged environments.
10. Can this probe be used in hazardous or explosive areas?
It can be installed in hazardous locations when used with appropriate certified protection systems and barriers.
Recommended Related Models (Same Series)
| Model | Description |
|---|---|
| 330101-00-76-10-02-00 | 8mm probe, 1.0 m cable length |
| 330101-00-92-10-02-05 | 8mm probe, 1.0 m cable, heavy-duty design |
| 330101-00-96-05-02-00 | 8mm probe, 0.5 m cable length |
| 330101-00-96-10-02-00 | 8mm probe, 1.0 m cable, standard build |
| 330101-00-08-10-02-00 | 8mm probe, compact size for restricted installations |
| 330101-00-16-05-02-00 | 8mm probe, 0.5 m cable, high-temperature variant |
