Bently Nevada 330101-23-39-10-12-05 3300 XL 8mm Proximity Probes

Product Introduction

The Bently Nevada 330101-23-39-10-12-05 is a high-precision 8mm proximity probe from the 3300 XL Proximity Transducer System. It is engineered for accurate shaft vibration and displacement measurement in critical rotating equipment. Designed to comply with API 670 standards, this probe provides reliable and consistent data for machinery protection, enabling early detection of rotor imbalances, misalignment, and dynamic instabilities.

This probe is widely used in power generation, petrochemical, oil & gas, and heavy industrial applications, where machine safety, performance optimization, and predictive maintenance are essential. Its robust design ensures stable operation under high temperatures, vibration, and other harsh industrial environments.

Product Specifications

Product Applications

The 330101-23-39-10-12-05 probe is intended for monitoring critical rotating machinery where reliability is vital. Applications include:

• Steam Turbines: Measuring axial displacement and vibration to ensure operational stability.

• Gas Compressors: Detecting rotor misalignment, imbalance, and dynamic changes.

• Centrifugal and Reciprocating Pumps: Monitoring shaft position and vibration to prevent mechanical failures.

• Electric Generators: Ensuring consistent operation and protecting against rotor faults.

• Industrial Fans and Blowers: Measuring runout and shaft vibration to maintain process reliability.

• Petrochemical and Oil & Gas Equipment: Continuous operation monitoring in high-temperature and hazardous environments.

Product Advantages

• API 670 Compliance: Fully meets global machinery protection standards.

• Durable Construction: Stainless steel housing resists corrosion and mechanical wear.

• Extended Temperature Range: Capable of operating from -35°C to +177°C.

• High Signal Accuracy: Minimizes noise, providing stable and reliable readings.

• Seamless Integration: Fully compatible with 3300 XL Proximitor sensors and monitoring systems.

• Field-Proven Reliability: Trusted worldwide for predictive maintenance and machinery protection.

• Versatile Applications: Effective for turbines, compressors, pumps, generators, and industrial fans.

FAQ

1. What is the output sensitivity of this probe?
   The output sensitivity is 7.87 V/mm (200 mV/mil), enabling precise monitoring of shaft vibration and displacement in high-speed rotating machinery.

2. What is the nominal gap for this probe?
   The nominal gap is 2.0 mm (80 mils), providing the optimal distance for linear and accurate signal measurement.

3. What is the linear range of the probe?
   The linear measurement range is 2.0 mm to 4.0 mm, ensuring reliable detection of shaft movement and vibration within the designed operating window.

4. What is the frequency response of the probe?
   The probe operates effectively in the frequency range of 0 to 10 kHz, capturing high-speed rotor dynamics and vibration signals accurately.

5. Can this probe be used in hazardous environments?
   Yes, it is designed for critical industrial environments, fully compliant with API 670 standards, and suitable for petrochemical and oil & gas facilities.

6. What type of connector does the probe use?
   The probe uses a Microdot connector, which ensures stable, low-noise electrical connections in industrial conditions.

7. Is the probe compatible with 3300 XL Proximitor sensors?
   Yes, it integrates seamlessly with 3300 XL Proximitor sensors and monitoring systems without additional modifications.

8. What is the insulation resistance of the probe?
   The insulation resistance exceeds 100 MΩ at 500 VDC, providing reliable electrical isolation for consistent operation.

9. What is the maximum operating temperature for this probe?
   The probe can operate in temperatures up to +177°C, making it suitable for high-temperature applications in turbines, compressors, and generators.

10. Does this probe comply with API 670 standards?
    Yes, the 330101-23-39-10-12-05 probe is fully API 670 compliant, ensuring reliable machinery protection and accurate condition monitoring.
