Product Introduction
The Bently Nevada 330103-00-10-50-02-00 is a robust, industrial-grade proximity probe that forms part of the 3300 XL 8mm series from Bently Nevada. It is engineered to provide precise, stable, and long-term vibration and position monitoring in high-speed rotating equipment. Known for its mechanical durability and electrical stability, this proximity probe is a critical component in condition monitoring systems, where equipment uptime and reliability are paramount.
This model features a 100 mm probe length, M10 x 1 threaded case, 5.0 meters of integral cable, and a durable ClickLoc™ connector that ensures secure and consistent electrical connection. It is typically paired with a 3300 XL extension cable and a 3300 XL Proximitor® sensor to complete the monitoring loop.
The 330103 series is widely recognized for delivering repeatable, high-fidelity displacement measurements even under demanding temperature, vibration, and electromagnetic conditions.
Product Specifications
| Specification | Details |
|---|---|
| Model Number | 330103-00-10-50-02-00 |
| Series | 3300 XL 8mm Proximity Probe Series |
| Tip Diameter | 8 mm (0.31 in) |
| Probe Length | 100 mm (3.94 in) |
| Thread Type | M10 x 1 |
| Thread Length | 50 mm (1.97 in) |
| Material – Probe Tip | PPS (Polyphenylene Sulfide) |
| Material – Probe Body | AISI 303/304 Stainless Steel |
| Total Length | 5 meters |
| Connector Type | ClickLoc™ Miniature Coaxial Connector |
| Sensing Range | 2.0 mm (80 mils) |
| Linear Range | 0.25 mm to 2.0 mm (10 to 80 mils) |
| Output Voltage Range | -2 VDC to -18 VDC typical |
| Sensitivity | 7.87 mV/μm (200 mV/mil) nominal |
| Operating Temperature | -35°C to +177°C (-31°F to +350°F) |
| Storage Temperature | -51°C to +177°C (-60°F to +350°F) |
| Environmental Sealing | Epoxy-sealed for industrial environments |
| Pressure Rating | Up to 500 psi (34 bar) |
| Weight | 1.615 kg |
| Compliance Standards | CE, RoHS, ATEX, CSA (for hazardous area certifications) |
Product Applications
The 330103-00-10-50-02-00 proximity probe is widely deployed in mission-critical machinery where vibration monitoring is essential for operational safety and predictive maintenance:
-
Steam and Gas Turbines
-
Centrifugal and Reciprocating Compressors
-
High-Speed Pumps and Electric Motors
-
Gearboxes and Blowers
-
Industrial Fans
-
Refinery and Petrochemical Equipment
-
Power Generation Units
-
Rotating Shafts and Thrust Bearing Monitoring
Product Advantages
-
Durable and Rugged Construction
The probe is built with stainless steel housing and an epoxy-sealed body to handle extreme conditions including high temperature, vibration, moisture, and contamination. -
High Measurement Precision
Designed for tight linearity across the full measuring range, with reliable output for both static and dynamic signals. -
ClickLoc™ Connector
Ensures a secure and reliable connection, even in areas with constant vibration or human intervention. -
EMI/RFI Immunity
Advanced shielding ensures accurate signal transmission in electrically noisy industrial environments. -
Global Certifications
Complies with CE, RoHS, and ATEX standards, making it suitable for global applications including hazardous zones. -
Flexible System Integration
Seamless integration with Bently Nevada 3300 XL Proximitor® sensors and monitoring systems like the 3500 series. -
Extended Service Life
Engineered to function over long durations without recalibration, reducing maintenance costs and downtime.
Frequently Asked Questions (FAQ)
-
What does the part number 330103-00-10-50-02-00 indicate?
It refers to a 100 mm probe length, M10 thread, 5.0 m integral cable, and ClickLoc connector configuration. -
What is the sensing range of this probe?
It has a sensing range of 2.0 mm (80 mils), with high linearity across that range. -
Can this probe operate in high-temperature zones?
Yes, it supports operation up to +177°C, suitable for turbine and compressor environments. -
Is it compatible with older Bently Nevada systems?
It is fully backward-compatible with many legacy Bently Nevada monitoring systems, particularly those using the 3300 XL platform. -
What type of sensor does this probe pair with?
It pairs with the 3300 XL Proximitor® sensor for signal conditioning and output scaling. -
Can the cable length be customized?
Yes, while this model features a 5.0 m cable, other lengths can be specified when ordering different variants. -
Does it require frequent calibration?
No, it is designed for long-term use without recalibration unless performance issues are observed. -
Is the probe tip replaceable?
No, the probe tip is fixed and not replaceable; if damaged, the entire probe assembly must be replaced. -
Is the probe suitable for offshore or corrosive environments?
Yes, the stainless-steel housing and sealed construction allow for installation in harsh or marine environments. -
Does this model support use in hazardous areas?
Yes, it meets ATEX and CSA certifications for use in hazardous zones classified for explosive gases or dust.
Related Models from the Same Series
| Model Number | Description | Probe Length | Thread Type | Cable Length |
|---|---|---|---|---|
| 330103-00-08-50-02-00 | 3300 XL 8mm Probe, 80 mm length | 80 mm | M10 x 1 | 5.0 m |
| 330103-00-05-10-02-00 | 3300 XL 8mm Probe, 50 mm, 10 ft cable | 50 mm | 3/8-24 UNF | 3.0 m |
| 330103-00-10-10-02-05 | 3300 XL 8mm Probe, 100 mm, 10 m cable | 100 mm | 3/8-24 UNF | 10.0 m |
| 330104-00-08-10-02-00 | 3300 XL 5mm Probe, M10 x 1, 8 mm length | 80 mm | M10 x 1 | 5.0 m |
| 330130-080-00-00 | Extension Cable for 3300 XL Series | N/A | N/A | 8.0 m |
| 330180-90-00 | Proximitor Sensor for 3300 XL Probes | N/A | N/A | N/A |
Popular Bently Nevada Models
| Model Number | Product Type | Description |
|---|---|---|
| 330103-00-10-05-02-00 | Proximity Probe | 8mm XL probe, 100 mm, 5 m cable |
| 3500/42M | Vibration Monitor Module | Measures shaft vibration using proximity probes |
| 330104-00-12-10-02-00 | 5mm XL Probe | Compact design, suited for restricted space |
| 330130-040-00 | Extension Cable | Coaxial extension cable, 4.0 meters |
| 3300 XL NSv 330901-00-12-10-02 | Proximity Probe (NSv Type) | Designed for narrow surface installations |
| 3500/22M | Transient Data Interface | Interfaces between monitor rack and external system (Modbus) |
