Bently Nevada 330104-00-06-10-01-00 3300 XL 8 mm Proximity Probe

Product Overview

The Bently Nevada 330104-00-06-10-01-00 is a precision 8 mm proximity probe from the trusted 3300 XL series. Designed for non-contact monitoring of rotating machinery, it provides highly accurate measurements of shaft displacement and vibration, essential for condition monitoring and predictive maintenance.

Built with durable stainless steel housing and advanced eddy current technology, this probe is engineered to perform reliably in extreme industrial environments. Its compact design and straight connector ensure easy installation and seamless integration with the Bently Nevada 3300 XL monitoring systems.

Key Features

• Non-contact vibration and shaft position sensing with eddy current technology

• Standard 8 mm probe tip with rugged 3300 XL design

• High-temperature tolerance up to +177°C

• Stainless steel construction for corrosion resistance

• Straight connector boot for simple cable routing

• Compatible with 3300 XL extension cables and Proximitor® sensor drivers

• API 670 compliant for machinery protection systems

Technical Specifications

Industry Applications

This probe is suitable for continuous monitoring in a variety of industries including:

• Power generation turbines and compressors

• Oil and gas pumps and motors

• Chemical processing rotating equipment

• Steel and metal rolling machinery

• Pulp and paper machinery

• Marine engine monitoring

Advantages

• Provides accurate, stable measurement of shaft position and vibration

• High durability with stainless steel housing suitable for harsh environments

• Long service life with minimal maintenance

• API 670 compliant ensuring industry-standard protection

• Easy installation with compact size and straight connector

• Compatible with existing 3300 XL monitoring infrastructure

• Enhances predictive maintenance capabilities to prevent costly failures

• Reduces unplanned downtime by early detection of machinery faults

Frequently Asked Questions (FAQ)

1. What is the cable length for this probe?
   The probe includes a 1.0 meter cable with a straight connector.

2. Is this probe suitable for high-temperature environments?
   Yes, it can operate up to +177°C.

3. What type of thread does the probe use?
   The probe uses an M10 x 1 thread size.

4. Is the probe compatible with older Bently Nevada systems?
   It is designed for 3300 XL systems; compatibility with older systems may vary.

5. What is the sensitivity of the probe?
   The sensitivity is 7.87 mV/μm (200 mV/mil).

6. Can this probe be used for vibration and shaft position measurement?
   Yes, it supports both static shaft position and dynamic vibration monitoring.

7. What material is the probe housing made of?
   The housing is stainless steel for corrosion resistance.

8. Does this probe require calibration?
   It is factory-calibrated and generally does not require field recalibration.

9. What is the linear measurement range?
   The linear range is 2 mm (80 mils).

10. What industries commonly use this probe?
    It is widely used in power generation, oil & gas, chemical processing, steel, pulp & paper, and marine industries.
