Product Introduction
The Bently Nevada 330104-00-16-10-02-05 is a key component of the 3300 XL 8 mm Proximity Transducer System, developed by Bently Nevada, a Baker Hughes company. This proximity probe is widely recognized in the industry for its durability, accuracy, and superior vibration monitoring in critical rotating machinery applications.
The 3300 XL 8 mm system provides non-contact measurements of shaft displacement, position, and vibration. It consists of a probe, extension cable, and proximitor sensor. The model 330104-00-16-10-02-05 specifically refers to the probe component with a tip diameter of 8 mm, designed for robust performance under high-temperature, high-vibration, and harsh industrial conditions.
As part of Bently Nevada’s trusted line of machine protection systems, this proximity probe is compliant with API 670 standards and is compatible with various monitoring systems. It is a preferred choice for engineers responsible for maintaining turbomachinery, compressors, pumps, and generators in oil & gas, petrochemical, and power industries.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 330104-00-16-10-02-05 |
| Product Type | Proximity Probe (8 mm) |
| System | 3300 XL 8 mm Proximity Transducer System |
| Tip Diameter | 8 mm |
| Thread Size | 3/8-24 UNF-2A |
| Thread Length | 1.0 inch (25.4 mm) |
| Case Material | AISI 303 Stainless Steel |
| Tip Material | Polyphenylene Sulfide (PPS) |
| Coating | Abrasion-resistant coating on probe cable |
| Target Material | AISI 4140 steel (standard calibration material) |
| Linear Range | 2 mm (80 mils) |
| System Sensitivity | 200 mV/mil (7.87 mV/µm) |
| Non-Linearity | ±0.25% of full-scale output |
| Temperature Range (Probe) | -51°C to +177°C (-60°F to +350°F) |
| Connector Type | Miniature coaxial connector |
| Total Length | 1 meters |
| Mounting Torque | 5 to 8 in-lbf (0.56 to 0.9 N·m) |
| API 670 Compliant | Yes |
| Ingress Protection | IP65 (when installed with proper connectors) |
| Weight | 0.323 kg |
| Application Suitability | Shaft vibration, axial position, and speed detection systems |
Applications
The Bently Nevada 330104-00-16-10-02-05 proximity probe is engineered for continuous monitoring of rotating equipment, particularly where high-precision and rugged sensing is necessary. Common applications include:
-
Steam & Gas Turbines: Monitoring shaft displacement and radial vibration.
-
Centrifugal Compressors: Ensuring real-time protection and diagnostics.
-
Industrial Pumps: Tracking shaft movement and wear to prevent seal failures.
-
Electric Generators: Vibration monitoring for condition-based maintenance.
-
Gearboxes and Fans: Used to measure rotor vibration and detect imbalance or misalignment.
-
Refinery and Petrochemical Plants: Embedded in critical process machinery.
-
Hydraulic Motors: Detecting early-stage failure via displacement signals.
-
Large Rotating Machines: General machinery health monitoring in power and manufacturing sectors.
Product Advantages
-
API 670 Compliance: Meets stringent international standards for machine protection systems.
-
High Reliability: Proven performance in extreme temperatures, vibration, and oil environments.
-
Non-contact Design: Reduces mechanical wear and improves maintenance intervals.
-
Robust Cable Construction: Abrasion-resistant jacket prolongs life in harsh routing scenarios.
-
Consistent Calibration: Factory calibration ensures high precision across systems.
-
Versatile System Integration: Compatible with a wide range of extension cables and proximitor modules.
-
Field-Proven Technology: Used globally in thousands of critical asset installations.
-
Compact and Durable Form: Easily embedded in tight spaces with secure mounting options.
Latest News Titles
-
Bently Nevada Expands 3300 XL Line for Greater Harsh Environment Support
-
330104 Series Probes Achieve New Reliability Milestones in Offshore Platforms
-
Machine Health Innovations Powered by Bently Nevada’s XL Proximity Technology
-
Bently Nevada Proximity Sensors Featured in Smart Maintenance Case Studies
-
API 670 Compliance Simplified with 3300 XL 8 mm Series Probes
-
Baker Hughes Showcases XL Probes in Digital Twin Integration Projects
-
330104-00-16-10-02-05 Plays Key Role in New Rotordynamics Lab
-
Bently Nevada Accelerates Condition Monitoring in LNG Terminals
-
Maintenance-Free Design of 3300 XL Series Praised by Global Operators
-
Bently Nevada Probes Integrated into Next-Gen Predictive Systems
Frequently Asked Questions (FAQ)
-
What does the part number 330104-00-16-10-02-05 specify?
It refers to a specific 8 mm probe with a 16-foot cable and standard mounting thread (3/8-24 UNF). -
Can this probe be used in high-temperature environments?
Yes, it is rated for up to +177°C (+350°F), making it suitable for steam turbines and compressors. -
Is the probe compatible with older 7200 and 3300 systems?
It is primarily designed for the 3300 XL system but backward compatibility is possible with appropriate modules. -
How is the probe typically installed?
It’s threaded into a probe holder or bracket using torque between 5–8 in-lbf and aligned toward the shaft. -
Does it require recalibration after installation?
Factory-calibrated, but verification against target material is recommended during commissioning. -
What extension cables are compatible with this probe?
It is compatible with Bently Nevada 330130 series extension cables. -
Can I use this probe with non-metallic targets?
No, the probe is calibrated for AISI 4140 steel. Other materials will require custom calibration. -
Is the probe immune to oil contamination?
Yes, designed to operate in oil-rich turbine and compressor housings. -
What is the sensitivity output of the probe?
200 mV/mil (7.87 mV/µm), consistent across the linear measurement range. -
Can this probe measure axial displacement?
Yes, it can be mounted axially to detect thrust movement in rotating equipment.
Related Models from the Same Series
| Model Number | Description | Cable Length | Thread Size | Application |
|---|---|---|---|---|
| 330104-00-05-10-02-00 | 8 mm Probe, 5 ft Cable, 3/8-24 UNF | 5 ft (1.5 m) | 3/8-24 UNF | General-purpose machinery |
| 330104-00-10-10-02-00 | 8 mm Probe, 10 ft Cable | 10 ft (3.0 m) | 3/8-24 UNF | Compressors and turbines |
| 330104-00-20-10-02-00 | 8 mm Probe, 20 ft Cable | 20 ft (6.1 m) | 3/8-24 UNF | Long-distance routing |
| 330104-00-25-10-02-00 | 8 mm Probe, 25 ft Cable | 25 ft (7.6 m) | 3/8-24 UNF | Remote installations |
| 330104-00-15-10-02-05 | 8 mm Probe, 15 ft Cable, 1/2-20 UNF | 15 ft (4.5 m) | 1/2-20 UNF | Oversized threads |
| 330104-00-10-10-01-00 | 8 mm Probe, 10 ft Cable, Straight Armored | 10 ft | 3/8-24 UNF | Rugged industrial conditions |
| 330104-00-16-10-01-00 | 8 mm Probe, 16 ft Cable, Armored | 16 ft | 3/8-24 UNF | High-wear environments |
| 330104-00-20-10-02-05 | 8 mm Probe, 20 ft Cable, 1/2-20 UNF | 20 ft | 1/2-20 UNF | Oversized mounting locations |
