Product Introduction
The Bently Nevada 330104-02-19-10-01-00 3300 XL 8 mm Proximity Probe is a high-precision, industrial-grade sensor designed to measure shaft displacement and vibration in rotating machinery. This probe is part of the renowned 3300 XL Series, widely recognized for its reliability, accuracy, and robustness in harsh industrial environments. The 3300 XL 8 mm Proximity Probe uses eddy-current technology to monitor machinery health by providing real-time feedback on displacement and vibration levels.
Designed for continuous, long-term operation, the 3300 XL 8 mm Proximity Probe is essential for condition monitoring systems in industries such as power generation, oil and gas, mining, and manufacturing. It helps detect early warning signs of mechanical issues, such as misalignment, imbalance, or bearing wear, which can lead to costly downtime or catastrophic failures if left unchecked.
The 3300 XL Proximity Probe is engineered to endure extreme conditions, including high temperatures, mechanical vibrations, and exposure to dust or chemicals. It provides highly accurate readings of shaft displacement without contact, which ensures long-term performance without wear and tear.
Product Parameters
Below is a table outlining the key parameters for the Bently Nevada 330104-02-19-10-01-00 3300 XL 8 mm Proximity Probe:
| Parameter | Value |
|---|---|
| Model | 330104-02-19-10-01-00 |
| Total Length | 1.0 meter |
| Weight | 0.323 kg |
| Sensing Range | ±8 mm |
| Probe Type | Eddy-current proximity probe |
| Temperature Range | -40°C to 120°C |
| Probe Diameter | 8 mm |
| Mounting Type | Fixed mount |
| Connector Type | 4-pin |
| Pressure Resistance | Up to 10 MPa |
| Vibration Resistance | High (suitable for harsh environments) |
| Operating Environment | Dust, moisture, and chemical resistant |
| Installation | Quick and easy, no calibration needed |
| Protection Class | IP65 (dust and water resistant) |
Product Applications
The Bently Nevada 330104-02-19-10-01-00 3300 XL 8 mm Proximity Probe is designed for a wide range of applications in industries where rotating machinery is essential. Its primary purpose is to monitor the displacement and vibration of machinery shafts, which is crucial for maintaining operational efficiency and preventing unplanned downtime. Below are some of the key applications:
-
Power Generation: The probe is widely used in power plants for monitoring turbines, generators, and other critical equipment. It helps in identifying mechanical problems, such as imbalance and misalignment, to prevent costly repairs or breakdowns.
-
Oil and Gas: In the oil and gas industry, this probe is essential for monitoring pumps, compressors, and turbines. Early detection of issues ensures smooth operations in harsh environments, minimizing downtime and maintenance costs.
-
Mining: Large-scale mining operations benefit from the precision of the 3300 XL probe to monitor crushers, mills, and other heavy machinery. By detecting early signs of damage, it helps avoid catastrophic failures.
-
Manufacturing: In manufacturing plants, the probe is used for condition monitoring of motors, conveyor systems, and other rotating equipment, contributing to improved machine reliability and productivity.
-
Chemical and Petrochemical Plants: The probe is resistant to harsh chemicals and extreme temperatures, making it ideal for use in chemical processing plants. It helps ensure equipment operates efficiently and detects early mechanical problems.
-
HVAC Systems: The 3300 XL probe plays a key role in monitoring rotating components like fans, pumps, and compressors in HVAC systems. Its accuracy helps to optimize system performance and avoid unexpected failures.
By measuring shaft displacement and vibration, the 3300 XL 8 mm Proximity Probe helps reduce the likelihood of equipment failure, enabling businesses to transition from reactive to proactive maintenance strategies.
Product Advantages
The Bently Nevada 330104-02-19-10-01-00 3300 XL 8 mm Proximity Probe offers a wide range of benefits for industries relying on the health of rotating machinery. Here are some of the key advantages:
-
Non-Contact Measurement: The probe uses eddy-current technology, which means no physical contact is needed for measuring displacement. This reduces wear and tear on the probe, enhancing its durability and ensuring long-term operation.
-
Precision and Sensitivity: With a high degree of sensitivity, the 3300 XL Proximity Probe is capable of detecting small changes in displacement, making it ideal for early fault detection.
-
Wide Temperature Range: The probe can operate in environments with temperatures ranging from -40°C to 120°C, ensuring reliable performance even in extreme conditions.
-
Long Sensing Range: The 8 mm sensing range offers versatility for a wide variety of industrial machinery, providing precise data even for larger equipment with significant displacement.
-
Durability in Harsh Environments: Built to withstand high vibrations, exposure to chemicals, and extreme temperatures, the probe is ideal for industrial settings where reliability is critical.
-
Easy Installation: The probe is designed for quick and easy installation with no complex calibration, which helps reduce installation time and operational downtime.
-
High Vibration Resistance: The probe’s design allows it to perform reliably even in environments with high levels of vibration, ensuring constant, accurate readings.
-
Preventative Maintenance: Early detection of issues such as misalignment or bearing wear allows for proactive maintenance, reducing the risk of sudden equipment failures.
-
Corrosion and Dust Resistant: The 3300 XL probe is resistant to corrosion, dust, and moisture, ensuring it works well in challenging conditions.
-
Cost-Effective: By minimizing the risk of unplanned downtime and reducing the need for emergency repairs, the probe offers significant long-term cost savings for operators.
Frequently Asked Questions (FAQs)
-
What is the main function of the Bently Nevada 330104-02-19-10-01-00 3300 XL 8 mm Proximity Probe?
It is used to measure shaft displacement and vibration in rotating machinery to detect mechanical faults such as misalignment, imbalance, and wear. -
How does the 3300 XL Proximity Probe work?
The probe uses eddy-current technology, which allows for precise measurements of shaft displacement without physical contact, preventing mechanical wear. -
What is the maximum temperature that the probe can handle?
The probe operates in temperatures ranging from -40°C to 120°C, making it suitable for both cold and hot environments. -
What is the sensing range of this proximity probe?
The 3300 XL 8 mm Proximity Probe has a sensing range of ±8 mm, making it ideal for various industrial applications. -
How easy is it to install the 3300 XL probe?
The probe is designed for quick and easy installation, requiring no complex calibration and reducing downtime during installation. -
What industries can benefit from the 3300 XL 8 mm Proximity Probe?
The probe is used across industries such as power generation, oil and gas, mining, manufacturing, chemical processing, and HVAC systems. -
What is the weight of the 3300 XL Proximity Probe?
The probe weighs 0.323 kg, which makes it easy to handle during installation and maintenance. -
What materials are the probe resistant to?
The 3300 XL probe is resistant to corrosion, dust, moisture, and chemicals, ensuring reliable performance in harsh industrial environments. -
What is the length of the 3300 XL 8 mm Proximity Probe?
The probe has a total length of 1.0 meter, providing flexibility for installation in various machinery applications. -
What is the advantage of using eddy-current technology?
Eddy-current technology allows for accurate, non-contact measurements of displacement, reducing wear and tear on the probe while ensuring precision and reliability.
