Product Introduction
The Bently Nevada 330104-08-14-05-01-00 proximity probe is a critical element of the trusted 3300 XL series, designed to deliver precise shaft position and vibration measurements for rotating machinery. Featuring an 8mm sensing distance, this probe enables accurate real-time monitoring that is essential for predictive maintenance and minimizing unplanned downtime in industrial equipment.
Manufactured with robust materials and designed for operation in demanding environments, this model stands out with its reliable performance across industries including power generation, petrochemical, mining, and manufacturing. Its proven durability and signal stability have made it a cornerstone in machinery condition monitoring systems worldwide.
Product Specifications
| Parameter | Details |
|---|---|
| Model Number | 330104-08-14-05-01-00 |
| Series | 3300 XL |
| Probe Type | Proximity Probe |
| Sensing Distance | 8 mm |
| Probe Tip Diameter | 14.0 mm |
| Probe Body Diameter | 14.0 mm |
| Total Length | 0.5 meter |
| Weight | 0.162 kg |
| Operating Temperature | -40°C to +120°C |
| Connector Type | MIL-C-26482 or equivalent |
| Output Signal | AC voltage proportional to gap |
| Housing Material | Stainless Steel |
| Protection Rating | IP67 |
| Mounting Method | Threaded mounting (M14 x 1.5) |
Applications
-
Power Generation: Monitoring turbines and generators to safeguard against mechanical faults.
-
Oil and Gas: Used in pumps, compressors, and rotating equipment in harsh environments.
-
Manufacturing: Vibration and position monitoring for motors, industrial fans, and pumps.
-
Mining: Durable performance in rugged environments, ensuring reliable machine monitoring.
-
Hydroelectric Plants: Accurate shaft position measurements for safe operations.
-
Aerospace: Used in test rigs and rotating machinery monitoring for performance validation.
Advantages
-
Precise Measurement: 8mm sensing distance ensures accurate shaft vibration and position detection.
-
Robust Build: Stainless steel housing with IP67 protection ensures durability in dust and moisture-prone environments.
-
Wide Temperature Range: Operates reliably from -40°C up to +120°C.
-
Secure Electrical Connection: MIL-C-26482 connector type provides a vibration-resistant, secure connection.
-
Simple Installation: Threaded M14 x 1.5 mounting allows for straightforward and secure mounting.
-
Customizable Cable Length: Flexible cable length options to accommodate installation requirements.
-
Proven Reliability: A trusted product within the 3300 XL series with extensive industrial use.
-
Stable Signal Output: Provides an AC voltage output proportional to the probe-to-target distance, ensuring dependable monitoring data.
Frequently Asked Questions (FAQ)
-
What is the sensing distance of the 330104-08-14-05-01-00 probe?
The sensing distance is 8 mm. -
Which industries primarily use this probe?
It is commonly used in power generation, oil and gas, manufacturing, mining, hydroelectric, and aerospace sectors. -
What is the standard Total Length included with the probe?
The standard total length is 0.5 meter, but custom lengths are available. -
What type of output signal does this probe provide?
It generates an AC voltage signal proportional to the gap between the probe and the target. -
How is the probe mounted?
The probe mounts via a threaded M14 x 1.5 connection. -
Is this probe suitable for harsh environmental conditions?
Yes, it features an IP67 protection rating and operates reliably between -40°C and +120°C. -
Is this probe compatible with all Bently Nevada 3300 XL systems?
Yes, it fully integrates with the 3300 XL condition monitoring systems. -
What maintenance is required?
Routine cleaning and inspection of the probe tip to maintain measurement accuracy. -
Can cable lengths be customized?
Yes, cable lengths can be tailored to meet specific installation needs. -
Can this probe be installed in hazardous areas?
Yes, with proper certifications and safety measures, it can be used in hazardous environments.
Recommended Related Models (Same Series or Related Proximity Probes)
| Model Number | Sensing Distance | Probe Diameter | Cable Length | Weight (kg) | Notes |
|---|---|---|---|---|---|
| 330101-00-40-10-12-05 | 8 mm | 12.7 mm | 2 m | 0.3 | Standard 8 mm proximity probe |
| 330103-00-40-10-12-05 | 12 mm | 12.7 mm | 2 m | 0.32 | Extended sensing distance |
| 330106-00-40-10-12-05 | 8 mm | 8 mm | 2 m | 0.28 | Smaller probe diameter |
| 330120-00-40-10-12-05 | 10 mm | 12.7 mm | 3 m | 0.35 | Longer cable option |
| 330130-00-40-10-12-05 | 8 mm | 12.7 mm | 5 m | 0.4 | Extended cable length |
| 330140-00-40-10-12-05 | 15 mm | 12.7 mm | 2 m | 0.36 | Maximum sensing distance in series |
Popular Bently Nevada Models (Widely Used Proximity Probes and Monitoring Equipment)
| Model Number | Product Type | Sensing Distance | Dimensions (mm) | Weight (kg) | Application Area |
|---|---|---|---|---|---|
| 330101-00-40-10-12-01 | Proximity Probe | 8 mm | 150 x 12.7 mm | 0.3 | Standard 3300 XL probe |
| 330103-00-40-10-12-01 | Proximity Probe | 12 mm | 150 x 12.7 mm | 0.32 | Extended sensing distance |
| 330141-00-40-10-12-01 | Proximity Probe | 20 mm | 150 x 12.7 mm | 0.38 | High sensing distance |
| 330200-00-00-00-00-01 | Vibration Transducer | N/A | 40 x 25 x 25 mm | 0.15 | Vibration measurement |
| 3500/05-00-00-00-00-00 | 3500 Series Monitor | N/A | 440 x 600 x 220 mm | 15 | Machinery protection system |
| 330106-00-40-10-12-01 | Proximity Probe | 8 mm | 150 x 8 mm | 0.28 | Smaller diameter probe |
