Product Introduction
The Bently Nevada 330106-05-30-20-02-00 3300 XL 8 mm Reverse Mount Probe is part of the trusted 3300 XL proximity transducer system, designed for precise vibration and displacement measurement in rotating machinery. This probe incorporates a reverse-mount design, allowing reliable performance in applications with restricted mounting space or unique installation requirements.
With an 8 mm sensing tip and a 2.0-meter total length cable, it delivers accurate eddy current-based proximity measurements that integrate seamlessly with Bently Nevada 3300 XL monitoring modules. Its rugged stainless-steel housing and ceramic sensing tip are engineered to withstand harsh industrial conditions, ensuring consistent performance in environments such as power plants, refineries, offshore platforms, and heavy machinery operations.
The probe provides stable operation across a wide range of temperatures and vibration intensities, making it essential for condition monitoring, predictive maintenance, and early fault detection in critical assets like turbines, compressors, pumps, and generators.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | 330106-05-30-20-02-00 |
| Series | 3300 XL |
| Probe Type | Reverse mount proximity probe |
| Probe Tip Diameter | 8 mm |
| Measurement Technology | Eddy current displacement sensing |
| Measurement Range | ±0.25 mm typical |
| Frequency Response | DC to 20 kHz |
| Total Length | 2.0 meters |
| Weight | 0.646 kg |
| Probe Body Length | 90 mm (excluding cable) |
| Connector Type | Integral MIL-style 4-pin connector |
| Materials | Stainless steel probe body, ceramic sensing tip |
| Operating Temperature | -40°C to +120°C (-40°F to +248°F) |
| Humidity | 0–95% RH, non-condensing |
| Maximum Shaft Speed | Up to 60,000 RPM (application dependent) |
| Certifications | CE, UL, CSA compliant |
Applications
The 330106-05-30-20-02-00 probe is widely used for monitoring critical machinery in industrial and energy production sectors. Its reverse mount design and extended 2-meter cable provide installation flexibility for a broad range of applications:
-
Steam and Gas Turbines: Ensures accurate vibration and shaft displacement monitoring for high-speed rotors.
-
Compressors: Prevents imbalance, misalignment, and bearing issues through continuous shaft position tracking.
-
Generators: Monitors rotor vibration and position to maintain operational reliability in power generation.
-
Industrial Pumps: Detects early-stage mechanical wear or shaft misalignment to prevent costly failures.
-
Petrochemical and Refining Equipment: Withstands demanding conditions in refineries and chemical plants.
-
Oil & Gas Installations: Provides reliable measurements in offshore and onshore facilities under harsh conditions.
Advantages
The Bently Nevada 330106-05-30-20-02-00 probe offers significant technical and operational benefits, making it a preferred choice in advanced machinery protection systems:
-
Reverse Mount Design: Ideal for space-constrained environments or non-standard installations.
-
High Measurement Accuracy: Ensures precise vibration and shaft displacement detection.
-
Extended Cable Length: 2-meter cable supports flexible probe placement without requiring additional extensions.
-
Durable Construction: Stainless steel body and ceramic tip provide excellent resistance to harsh operating conditions.
-
Seamless Compatibility: Integrates with 3300 XL system components for consistent measurement reliability.
-
Wide Operating Range: Functions effectively across extreme temperature and humidity variations.
-
High-Speed Capability: Suitable for monitoring shafts operating at speeds up to 60,000 RPM.
-
Certified for Safety: Meets international CE, UL, and CSA standards for global industrial use.
FAQ
-
What sensing principle does this probe use?
It uses eddy current technology to measure vibration and displacement. -
What is the maximum frequency response supported?
The probe supports DC to 20 kHz frequency response. -
Is the probe suitable for reverse mounting applications?
Yes, it is specifically designed for reverse mount installations. -
What is the maximum shaft speed that can be monitored?
It can monitor machinery with shaft speeds up to 60,000 RPM, depending on system configuration. -
How does the probe connect to the monitoring system?
Through an integral 4-pin MIL-style connector compatible with 3300 XL systems. -
What is the typical displacement measurement range?
±0.25 mm for accurate shaft position monitoring. -
Can this probe be used in high-vibration environments?
Yes, it is engineered for stable performance under extreme vibration conditions. -
What materials are used in the probe construction?
Stainless steel for the probe body and ceramic for the probe tip. -
Which monitoring systems are compatible with this probe?
It is fully compatible with all Bently Nevada 3300 XL monitoring modules. -
What environmental conditions can the probe operate under?
It supports operation from -40°C to +120°C and 0–95% non-condensing humidity.
