Bently Nevada 330180-X0-00 145004-115 3300 XL 8mm Proximitor Sensor

Product Introduction

The Bently Nevada 330180-X0-00 / 145004-115 – 3300 XL 8mm Proximitor Sensor is a high-precision, non-contact eddy current proximity probe designed to detect the dynamic and static displacement of rotating machinery shafts. As a critical component of the 3300 XL series, this sensor is widely used in condition monitoring and protection systems for critical rotating equipment such as turbines, compressors, motors, and gearboxes.

The 3300 XL 8mm system is engineered to deliver high accuracy, robust environmental resistance, and low signal noise, making it ideal for harsh industrial conditions. When used with a matching extension cable and Proximitor® driver, the system outputs a highly linear voltage signal that represents the shaft’s relative motion and position.

The 145004-115 variant is part of the 330180 probe family, with specific mechanical or connector features designed to meet application-specific installation or regulatory requirements. With its reputation for ruggedness and field-proven performance, this sensor plays a key role in API 670-compliant machinery protection systems.

---

Product Specifications

---

Product Applications

The 330180-X0-00 / 145004-115 8mm Proximitor Sensor is utilized in high-value rotating machinery where real-time monitoring of shaft movement, vibration, and positioning is critical for operational safety and performance optimization. Key application areas include:

• Steam and Gas Turbines
  For measuring rotor shaft axial position and dynamic vibration to prevent rubs or imbalance.

• Centrifugal and Reciprocating Compressors
  Used for rod drop, shaft orbit, and phase reference monitoring.

• Large AC/DC Motors and Generators
  Installed to track bearing wear, shaft alignment, and looseness.

• Petrochemical Pumps and API Machinery
  Enables machinery to comply with API 670 protection system requirements.

• Industrial Fans, Blowers, and Gear Drives
  Provides feedback for real-time monitoring, predictive maintenance, and shutdown protection.

• Power Plants and Refinery Critical Equipment
  Integrated into safety and control systems for continuous, 24/7 monitoring.

---

Product Advantages

• High Signal Accuracy and Stability
  Delivers precise measurements with minimal drift or temperature influence over time.

• Field-Proven Reliability
  Thousands of installations worldwide demonstrate robust performance in demanding environments.

• Rugged, Hermetically Sealed Construction
  Fully sealed against dust, oil, moisture, and chemical exposure—ideal for harsh industrial zones.

• Flexible System Compatibility
  Easily integrates with 3300 XL Proximitor modules and other Bently Nevada systems.

• Extended Temperature Range
  Operates safely at up to +177°C at the probe tip, suitable for high-heat applications.

• EMI/RFI Shielded Cabling
  Ensures signal integrity in electrically noisy environments such as substations or near high-voltage equipment.

• API 670 Compliance
  Designed to meet or exceed the standards for shaft vibration and position measurement in critical rotating equipment.

• Minimal Maintenance Required
  Long operational lifespan with low maintenance frequency, reducing system downtime and service costs.

• Customizable Lengths and Mounting Threads
  Supports a variety of configurations to suit different machinery and space constraints.

• Designed for Predictive Maintenance Systems
  Enables early detection of equipment faults, reducing unplanned outages and repair costs.

---
