Product Introduction
The Bently Nevada 330180-X1-CN (Part No. 145193-09) is a high-performance 3300 XL 8mm Proximitor Sensor specifically engineered for demanding industrial environments where accurate, reliable proximity measurements are essential. This sensor is widely used in rotating machinery monitoring systems, providing precise shaft position and vibration data that is critical for the health and safety of turbines, compressors, pumps, motors, and generators.
Designed as part of the trusted 3300 XL Series, this sensor features enhanced EMI/RFI immunity, extended temperature tolerance, and long-term stability in harsh environments. The robust design makes it ideal for integration into both existing and new condition monitoring systems.
Product Specifications
| Parameter | Details |
| Model Number | 330180-X1-CN |
| Part Number | 145193-09 |
| Series | 3300 XL |
| Sensor Type | 8mm Proximitor Sensor |
| Measurement Range | 2 mm (80 mils), linear range |
| Linear Output Voltage | 200 mV/mil (7.87 mV/μm) ±5% |
| Power Supply Voltage | –24 VDC (nominal), two-wire system |
| Frequency Response | Up to 10 kHz |
| Mounting Thread | 3/8-24 UNF-2A or M10 |
| Cable Length Options | Configurable: 1–9 meters (X1 denotes length, e.g., X1=5m) |
| Connector Type | MIL-C-5015 connector or click-on connector |
| Operating Temperature | –35°C to +100°C |
| Storage Temperature | –50°C to +120°C |
| Humidity Tolerance | 95% non-condensing |
| EMI/RFI Protection | Enhanced, industrial grade |
| Weight | 0.246 kg |
| Dimensions | 81.3 x 35.1 x 63.5 mm |
| Compliance | CE, RoHS, ATEX (select variants) |
| Field Compatibility | Compatible with all 3300 XL probes and extension cables |
Applications
The 330180-X1-CN Proximitor Sensor is suitable for a wide range of industrial monitoring applications, particularly where precision and durability are vital:
-
Steam, gas, and hydro turbines
-
Industrial compressors
-
Gearboxes and generators
-
Pumps and fans
-
Electric motors
-
Critical rotating machinery in oil & gas, power generation, and chemical processing industries
Product Advantages
-
High Accuracy & Stability: Delivers consistent, linear output for proximity and vibration measurements even in fluctuating temperatures and electromagnetic environments.
-
Robust Industrial Design: Built to withstand harsh industrial conditions including vibration, oil contamination, and high humidity.
-
Field Proven: Part of the widely adopted 3300 XL series, trusted by OEMs and end-users globally.
-
Modular & Configurable: Interchangeable with other XL components, allowing for flexible installations.
-
Long Cable Runs Supported: Maintains signal integrity over long extension cable distances (up to 9 meters).
-
Global Certifications: Available in versions that meet ATEX and CE requirements for hazardous environments.
