The Bently Nevada 330904-07-15-05-02-00 3300 NSv Proximity Probe is a high-precision, non-contact displacement sensor engineered for use in rotating machinery vibration monitoring and shaft position measurement. It is part of the 3300 NSv series, which is designed for installations with restricted space and small machinery shafts.

This probe functions using the eddy current principle, detecting changes in the electromagnetic field generated near a conductive target surface. This allows it to provide highly accurate and linear measurement of both static shaft position and dynamic vibration signals. The 330904-07-15-05-02-00 model is commonly used in conjunction with Bently Nevada 3300 NSv Proximitor modules and extension cables, forming a complete monitoring system that adheres to API 670 machinery protection standards.

The compact design, combined with a robust stainless steel housing, makes this probe suitable for applications in turbines, compressors, pumps, and small motors, providing reliable early warning of mechanical issues, reducing downtime, and enhancing overall equipment reliability.

---

Technical Specifications

---

Product Applications

The 330904-07-15-05-02-00 probe is widely used in industrial machinery monitoring where precision and compact size are essential. Key applications include:

• Small Steam and Gas Turbines: Shaft vibration and position monitoring under varying loads.

• Industrial Compressors: Early detection of imbalance, misalignment, or rotor looseness.

• Pumps and Electric Motors: Continuous condition monitoring for predictive maintenance.

• Gearboxes and Fans: Detection of vibration, rotor instability, and mechanical looseness.

• Marine and Aerospace Applications: Compact rotating systems requiring precise measurement.

This probe is critical for forming complete NSv monitoring chains, providing real-time data for predictive maintenance and operational safety.

---

Product Advantages

• High Accuracy: Maintains linearity within ±1% across full measurement range.

• Compact Design: Ideal for tight installations and small machinery shafts.

• Robust Construction: Stainless steel housing ensures long-term reliability in harsh environments.

• Temperature Stability: Performs accurately over a wide temperature range.

• EMI Shielding: Coaxial cable design minimizes electromagnetic interference.

• API 670 Compliant: Integrates seamlessly with Bently Nevada vibration monitoring systems.

• Non-contact Operation: Eliminates mechanical wear, reducing maintenance needs.

• Low Noise Output: Ensures precise readings for diagnostic and monitoring systems.

• Easy Installation: Threaded mounting simplifies setup and replacement.

• Versatile Compatibility: Works with standard NSv Proximitor modules and extension cables.

---

FAQ

1. What principle does the 330904-07-15-05-02-00 use for measurement?
   It uses eddy current sensing to detect variations in the distance between the probe tip and a conductive target.

2. Which Proximitor sensor is compatible with this probe?
   It is designed for use with Bently Nevada 3300 NSv Proximitor modules for optimal performance.

3. Can it measure both static and dynamic displacement?
   Yes, it provides real-time data for both static shaft position and dynamic vibration signals.

4. What is the frequency range of this probe?
   It supports a 0 to 10 kHz frequency response, suitable for high-speed rotating machinery.

5. Is it suitable for oil-lubricated bearing housings?
   Yes, the sealed design allows operation in oil-contaminated environments.

6. How does the probe maintain accuracy in varying temperatures?
   Temperature-compensated calibration and stable construction ensure minimal drift.

7. Can the probe cable be extended?
   Only use factory-approved NSv extension cables to maintain accuracy and signal integrity.

8. How is the probe installed?
   The probe is mounted using an M8 threaded connection, tightened with a lock nut to specified torque.

9. Is the probe shielded from electromagnetic interference?
   Yes, the coaxial cable and probe assembly provide strong EMI and RFI resistance.

10. Can it integrate with Bently Nevada 3500 monitoring racks?
    Yes, it is fully compatible when used with NSv extension cables and Proximitor sensors.

---
