Product Introduction
The Bently Nevada 330905-00-25-05-02-05 is a 3300 NSv (Narrow Side View) proximity probe specifically engineered for applications requiring close-range shaft vibration and position monitoring where space constraints limit probe installation. Designed for use in conjunction with compatible NSv extension cables and drivers, this 0.5-meter proximity probe offers reliable, high-precision measurement of shaft dynamic motion, making it particularly suited for small or tight clearances in machines like gearboxes, small turbines, or compact rotating equipment.
The 330905 series leverages non-contact eddy current sensing technology to detect conductive surface displacement, offering non-intrusive, continuous monitoring without physical contact. Its rugged stainless-steel construction, shielded cabling, and compliance with API 670 standards ensure exceptional performance in industrial environments such as oil and gas, petrochemicals, and power generation. With a shipping weight of 2 kg, the product is robust and carefully packaged to prevent transport damage.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | 330905-00-25-05-02-05 |
| Product Series | 3300 NSv Proximity Transducer System |
| Sensing Technology | Eddy Current (non-contact) |
| Probe Type | NSv (Narrow Side View), Metric |
| Total Probe Length | 0.5 meters |
| Probe Tip Diameter | 5 mm (metric version) |
| Thread Size | M8 x 1.0 |
| Measurement Range | 0 – 1.27 mm (± 0.063 mm linear) |
| Sensitivity | 7.87 mV/μm (200 mV/mil nominal) |
| Linear Range | ± 0.063 mm around 1.0 mm target gap |
| Housing Material | Stainless steel |
| Operating Temperature | –35°C to +175°C |
| Environmental Protection | Hermetically sealed |
| Vibration Rating | Meets API 670 & IEC standards |
| Cable Connection | Integral with connector or extension cable |
| Compatibility | Bently Nevada 3300 NSv drivers and cables |
| Shipping Weight | 2.0 kg |
Product Applications
The 330905-00-25-05-02-05 proximity probe is designed for high-accuracy, real-time monitoring of shaft vibration and relative displacement in compact or lightly loaded rotating machinery. Applications include:
-
Small Steam & Gas Turbines: Precise monitoring of shaft position in turbines with tight radial clearances.
-
Gearboxes: Detects gear misalignment, wear, and early fault conditions in constrained environments.
-
Turboexpanders: Used in cryogenic and petrochemical systems where small shaft sizes require NSv geometry.
-
Compressors: Supports condition-based maintenance by measuring shaft behavior under load.
-
Pumps and Motors: Monitors dynamic movement in compact or vertically mounted rotating machinery.
-
OEM Equipment: Ideal for equipment manufacturers needing compact sensor integration without compromising accuracy.
Product Advantages
-
Compact NSv Design – Enables installation in limited-space applications where standard probes cannot be used.
-
High Sensitivity and Accuracy – Offers a tight linear range and accurate measurement resolution for small displacement values.
-
Non-Contact Sensing – Eliminates mechanical wear while providing continuous, real-time monitoring.
-
Stainless Steel Housing – Withstands harsh chemical, thermal, and vibration environments.
-
Seamless Integration – Fully compatible with Bently Nevada 3300 NSv system components including drivers and extension cables.
-
Metric Threading – Simplifies installation in systems following metric engineering standards.
-
API 670 Compliance – Meets globally recognized standards for machine protection and reliability.
-
Flexible Cable Configurations – Supports different cable lengths and connector styles based on application needs.
-
Hermetically Sealed Construction – Protects internal components from moisture and particulates, improving MTBF.
-
Global Industry Acceptance – Trusted by OEMs and end users in oil & gas, power, and process industries worldwide.
Frequently Asked Questions (FAQ)
Q1: What is the primary use of the 330905-00-25-05-02-05 probe?
A1: It is used to monitor the vibration and shaft displacement in compact rotating machinery where standard proximity probes cannot fit.
Q2: What is the length of the probe and its weight when shipped?
A2: The probe has a total length of 0.5 meters and a shipping weight of 2.0 kg.
Q3: Can this probe be used in high-temperature environments?
A3: Yes, it operates effectively in environments up to +175°C.
Q4: Is this probe compliant with API 670?
A4: Yes, it meets the API 670 standard for vibration monitoring in rotating machinery.
Q5: What equipment is this probe commonly used with?
A5: It’s widely used with turbines, gearboxes, turboexpanders, and compact motors.
Q6: How does the NSv design differ from standard probes?
A6: The NSv design allows side-view sensing in limited spaces, offering a narrower profile without sacrificing accuracy.
Q7: Is this probe compatible with older Bently Nevada systems?
A7: It is compatible with the 3300 NSv system but may require matching drivers and cables.
Q8: How is the probe mounted to equipment?
A8: It features an M8 x 1.0 threaded body for secure, precise mounting into custom or standard probe holders.
Q9: What kind of output signal does this probe generate?
A9: It produces a voltage output proportional to the shaft’s displacement from the probe tip, typically 7.87 mV/μm.
Q10: Can the probe be used in hazardous environments?
A10: With proper installation and certification, it can be used in classified hazardous zones.
Recommended Models – Same Series / Related
| Model | Description | Key Feature |
|---|---|---|
| 330905-00-12-05-02-05 | 3300 NSv 8 mm probe, 1.2 m cable | Longer cable for extended reach |
| 330905-00-08-10-01-00 | 3300 NSv probe, 0.8 m cable | Mid-range cable length |
| 330905-00-25-05-02-00 | 3300 NSv probe with standard connector | Alternate connector configuration |
| 330905-00-20-10-02-05 | 3300 NSv, 2.0 m probe, metric | Long-reach version, metric thread |
| 330105-02-12-10-02-00 | 3300 XL 8 mm standard proximity probe | Larger diameter, broader use case |
| 330103-00-05-10-02-00 | 3300 XL 5 mm compact probe | Ideal for smaller shaft diameters |
Recommended Models – Same Brand (Bently Nevada Hot Sellers)
| Model | Description | Dimensions (mm) |
|---|---|---|
| 330905-00-13-05-02-05 | 3300 NSv proximity probe, 5 m cable, 8 mm tip, standard connector | 91 x 13 x 13 |
| 330905-00-13-10-12-CN | 3300 NSv probe, 10 m cable, metric thread, Chinese version | 91 x 13 x 13 |
| 330905-00-15-05-02-00 | 3300 NSv proximity probe, 5 m cable, enhanced armor, 3/8-24 UNF thread | 91 x 13 x 13 |
| 330905-00-13-10-02-00 | 3300 NSv probe, 10 m cable, 8 mm tip, without armor | 91 x 13 x 13 |
| 330905-00-14-05-02-05 | 3300 NSv probe, 5 m armored cable, standard configuration | 91 x 13 x 13 |
| 330905-00-15-10-02-CN | 3300 NSv probe, 10 m cable, armored, Chinese labeling | 91 x 13 x 13 |
