Bently Nevada 330906-02-12-05-05-02-05 3300 NSv Reverse Mount Probe

Company Information
E-mail		[email protected]
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The Bently Nevada 330906-02-12-05-05-02-05 3300 NSv Reverse Mount Probe is a high-precision, non-contact displacement sensor designed for industrial machinery where reverse or compact mounting configurations are required. This probe is part of the 3300 NSv series, engineered to provide reliable shaft position and vibration measurements even in constrained spaces where standard probes cannot be installed.

Operating on the eddy current principle, the probe measures variations in the electromagnetic field caused by the proximity of a conductive target. This allows for accurate detection of static shaft position and dynamic vibration signals, making it an essential component in rotor health monitoring and predictive maintenance systems. The reverse-mount design enhances flexibility for machinery layouts with limited space or unusual mounting orientations.

Its stainless steel housing ensures durability in challenging industrial environments, and its integration with 3300 NSv Proximitor modules supports full system compatibility for API 670 machinery protection standards. Typical applications include turbines, compressors, pumps, and motors.

---

Technical Specifications

---

Product Applications

The 330906-02-12-05-05-02-05 probe is widely used in industrial machinery where space constraints or reverse mounting are required. Key applications include:

• Steam and Gas Turbines: Measures both dynamic and static shaft displacement in reverse-mount configurations.

• Industrial Compressors: Detects rotor imbalance, misalignment, and mechanical looseness.

• Pumps and Motors: Enables continuous condition monitoring for predictive maintenance.

• Gearboxes and Fans: Monitors shaft stability and detects early-stage mechanical issues.

• Tight or Compact Machinery Layouts: Allows installation where standard probes cannot fit.

This probe is fully compatible with 3300 NSv Proximitor modules, ensuring accurate real-time data collection for machinery protection and diagnostics.

---

Product Advantages

• High Measurement Accuracy: ±1% linearity across the measurement range.

• Reverse Mount Design: Ideal for space-constrained or non-standard installations.

• Durable Construction: Stainless steel housing provides resistance to corrosion and mechanical wear.

• Wide Operating Temperature Range: Reliable operation from –35°C to +180°C.

• EMI Resistant: Coaxial design reduces interference from electromagnetic noise.

• API 670 Compliant: Suitable for industrial machinery protection systems.

• Non-contact Measurement: Reduces maintenance requirements and eliminates mechanical wear.

• Low Output Noise: Provides stable and precise signal output.

• Simple Installation: Reverse-mount configuration with lock nut ensures secure placement.

• Seamless Integration: Works with NSv Proximitor modules for complete system compatibility.

---

FAQ

1. What measurement principle does this probe use?
   It uses eddy current sensing to measure the distance between the probe tip and a conductive target, providing precise static and dynamic shaft data without contact.

2. Which Proximitor modules are compatible with this reverse-mount probe?
   It is designed for use with Bently Nevada 3300 NSv Proximitor modules to ensure accurate signal conditioning and full system integration.

3. Can it measure static and dynamic displacement simultaneously?
   Yes, it captures real-time static shaft position while also detecting vibration signals, enabling predictive maintenance.

4. What is the probe’s frequency response?
   The probe operates from DC to 10 kHz, suitable for monitoring low-frequency shaft displacement and high-frequency vibration.

5. Is the probe suitable for operation in oil-lubricated bearings or harsh environments?
   Yes, its hermetically sealed stainless steel housing allows operation in oil, moisture, and high-temperature conditions.

6. How is the probe calibrated, and how accurate is it?
   It is factory-calibrated using standard steel targets and maintains ±5% system-level accuracy when installed properly.

7. Is the probe resistant to electromagnetic interference?
   Yes, the coaxial design and shielding minimize EMI, providing stable and accurate readings even in electrically noisy environments.

8. Can the probe cable be extended?
   Only factory-approved NSv extension cables should be used to preserve calibration and signal integrity.

9. What is the recommended mounting method?
   Use the M8 threaded connection and secure with the lock nut to specified torque for consistent performance.

10. Can this probe be integrated into 3500 monitoring systems?
    Yes, it integrates through NSv Proximitor modules and approved extension cables, providing reliable vibration and shaft position data for machinery protection.

---
