Product Introduction
The Bently Nevada 330910-02-08-70-01-00 is a 3300 NSv Proximity Probe designed for high-precision shaft displacement monitoring in rotating machinery. This probe is part of the 3300 Series, which is widely recognized for its reliability in vibration and position measurement applications in turbines, compressors, motors, and generators. The probe converts shaft displacement into an electrical signal for real-time monitoring and analysis, supporting machinery protection and predictive maintenance programs.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | 330910-02-08-70-01-00 |
| Sensor Type | Eddy-Current Proximity Probe |
| Probe Tip Diameter | 8 mm |
| Total Length | 7 m |
| Weight | 0.15 kg |
| Operating Temperature | -40°C to 120°C |
| Measurement Range | ±0.254 mm (±10 mils) |
| Sensitivity | 10 mV/mil |
| Electrical Interface | 2-wire differential |
| Maximum Frequency Response | 10 kHz |
| Mounting Type | Threaded (standard 10-32 UNF) |
| Insulation Resistance | >100 MΩ |
Product Applications
-
High-speed turbines in power generation
-
Centrifugal and axial compressors
-
Industrial pumps and motors
-
Gas and steam turbines
-
Critical rotating machinery requiring shaft vibration and position monitoring
-
Machinery diagnostic systems for predictive maintenance
Product Advantages
-
High precision with stable sensitivity over a wide temperature range
-
Rugged design suitable for harsh industrial environments
-
Wide frequency response for capturing high-speed vibrations
-
Reliable and repeatable measurements to prevent machinery failure
-
Compatible with Bently Nevada 3300 Series monitoring systems
-
Easy installation with standard threaded mounting and pre-terminated cable
FAQ
Q1: What is the maximum operating frequency of the 330910-02-08-70-01-00 probe?
A1: The maximum frequency response is 10 kHz, suitable for high-speed machinery monitoring.
Q2: Is the probe compatible with all 3300 Series monitoring modules?
A2: Yes, it is fully compatible with standard 3300 Series proximity monitoring systems.
Q3: What is the electrical output type of the probe?
A3: The probe provides a 2-wire differential output for signal transmission.
Q4: Can this probe be used in high-temperature environments?
A4: Yes, it operates reliably from -40°C to 120°C.
Q5: What is the typical sensitivity of the probe?
A5: The probe has a sensitivity of 10 mV/mil.
Q6: Does the probe support monitoring of axial shaft displacement?
A6: Yes, it can accurately measure both radial and axial shaft movements within the specified range.
Q7: What type of mounting does this probe use?
A7: Standard threaded mounting (10-32 UNF) is used for secure and repeatable installation.
Q8: Is the probe suitable for detecting high-frequency vibration?
A8: Yes, with a frequency response up to 10 kHz, it captures high-speed vibrations effectively.
Q9: What is the measurement range of the probe?
A9: The measurement range is ±0.254 mm (±10 mils).
Q10: Can this probe be used in gas turbine applications?
A10: Yes, it is widely used in gas turbines, steam turbines, and other critical rotating equipment.
Recommended 6 Same-Series or Related Models
| Model Number | Probe Tip Diameter | Cable Length | Weight |
|---|---|---|---|
| 330910-02-06-50-01-00 | 6 mm | 1 m | 0.14 kg |
| 330910-02-08-50-01-00 | 8 mm | 1 m | 0.15 kg |
| 330910-02-10-70-01-00 | 10 mm | 1 m | 0.16 kg |
| 330910-02-06-70-01-00 | 6 mm | 1 m | 0.14 kg |
| 330910-02-08-70-02-00 | 8 mm | 2 m | 0.17 kg |
| 330910-02-10-50-01-00 | 10 mm | 1 m | 0.16 kg |
6 Popular Models from Bently Nevada
| Model Number | Description | Probe Tip Diameter | Weight |
|---|---|---|---|
| 330910-00-08-50-02-05 | 3300 NSv Proximity Probe | 8 mm | 0.15 kg |
| 330910-00-10-50-02-05 | 3300 NSv Proximity Probe | 10 mm | 0.16 kg |
| 330910-02-06-70-01-00 | 3300 NSv Proximity Probe | 6 mm | 0.14 kg |
| 330910-00-08-70-01-00 | 3300 NSv Proximity Probe | 8 mm | 0.15 kg |
| 330910-02-08-50-02-00 | 3300 NSv Proximity Probe | 8 mm | 0.15 kg |
| 330910-00-06-50-01-00 | 3300 NSv Proximity Probe | 6 mm | 0.14 kg |
