Product Introduction
The Bently Nevada 3500/15-03-02-00 is a key component of the industry-leading 3500 monitoring system designed for critical machinery protection and condition monitoring. This module serves as a versatile transducer interface, allowing seamless integration of multiple sensor types into the 3500 rack system. Its robust design and advanced signal conditioning capabilities enable precise monitoring of vibration, proximity, and other process parameters, which is essential for predictive maintenance and avoiding costly unplanned downtime.
Developed with decades of field experience, the 3500/15-03-02-00 ensures high reliability, excellent signal fidelity, and straightforward installation. It supports the demanding needs of rotating equipment monitoring in various industries such as power generation, oil and gas, petrochemical, and manufacturing.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | 3500/15-03-02-00 |
| Function | Proximity/Displacement Transducer Module |
| Input Signal Type | Variable Reluctance Proximity Probe (VRPP) |
| Output Signal | Processed vibration and displacement signals |
| Power Supply | +24 V DC (supplied by 3500 rack) |
| Dimensions | 120.7 x 50.8 x 251.5mm |
| Weight | 1.39 kg |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Storage Temperature | -55°C to +100°C (-67°F to +212°F) |
| Humidity | Up to 95% non-condensing |
| Communication Interface | Backplane connection to 3500 rack |
| Mounting | 3500 rack chassis slot |
Product Applications
-
Monitoring vibration and displacement on critical rotating equipment such as turbines, compressors, pumps, and motors.
-
Providing early warnings of machinery faults including imbalance, misalignment, bearing wear, and shaft rub.
-
Supporting condition-based maintenance strategies by providing reliable, real-time data.
-
Enhancing plant safety and reliability by preventing catastrophic failures.
-
Widely used in power plants, oil refineries, petrochemical complexes, pulp and paper mills, and heavy manufacturing industries.
-
Integration with Bently Nevada System 3500 allows centralized monitoring and diagnostics.
Product Advantages
-
High Accuracy and Reliability: Engineered for precise measurement of proximity and vibration signals, ensuring dependable data for critical decisions.
-
Robust Design: Built to withstand harsh industrial environments including wide temperature and humidity ranges.
-
Ease of Installation and Maintenance: Modular design compatible with standard 3500 rack chassis, simplifying upgrades and replacements.
-
Versatile Input Compatibility: Supports variable reluctance probes, a standard sensor type widely used in machinery monitoring.
-
Signal Conditioning: Advanced onboard signal processing reduces noise and enhances signal clarity.
-
System Integration: Seamlessly works with Bently Nevada 3500 system components and software, allowing easy setup and comprehensive diagnostics.
-
Industry Proven: Backed by decades of Bently Nevada expertise in vibration monitoring technology and global field support.
FAQ
Q1: What types of sensors are compatible with the 3500/15-03-02-00 module?
A1: This module is specifically designed for use with Variable Reluctance Proximity Probes (VRPP), commonly used for displacement and vibration measurement.
Q2: Can this module be used outside the Bently Nevada 3500 rack system?
A2: No, it is designed to be installed and operated within the 3500 rack chassis, leveraging the rack’s power supply and communication backplane.
Q3: What is the typical lifespan of this module?
A3: With proper use and maintenance, the module typically operates reliably for many years; many installations report over 5 years of service.
Q4: How does this module contribute to machinery safety?
A4: By continuously monitoring key vibration parameters, it provides early detection of faults that could lead to catastrophic equipment failure, enabling timely maintenance.
Q5: Is the 3500/15-03-02-00 module suitable for hazardous environments?
A5: While the module is robust and rated for industrial conditions, specific hazardous area certifications should be verified per installation requirements.
Q6: How is the module powered?
A6: It receives +24 V DC power from the 3500 rack backplane; no external power supply is needed.
Q7: What is the communication method for data retrieval?
A7: The module communicates via the 3500 rack’s backplane to the system processor, which interfaces with plant monitoring software.
Q8: Can this module monitor multiple probes simultaneously?
A8: Typically, one module supports one or two proximity probes depending on the configuration.
Q9: What maintenance is required for the 3500/15-03-02-00 module?
A9: Routine visual inspections and system diagnostics are recommended; the module itself requires minimal maintenance.
Q10: What is the operating temperature range for this module?
A10: It is designed to operate reliably between -40°C and +85°C (-40°F to +185°F).
Recommended Models (Same Series or Related)
| Model Number | Description |
|---|---|
| 3500/15-02-05-00 | Proximity Module with signal isolation |
| 3500/15-03-05-00 | Advanced vibration transducer module |
| 3500/15-03-03-00 | Displacement sensor interface module |
| 3500/15-01-02-00 | AC power supply module |
| 3500/15-05-00-00 | Relay output module |
| 3500/15-06-00-00 | Digital input module |
Popular Bently Nevada Models (Same Brand)
| Model Number | Description | Dimensions (WxHxD) | Weight | Voltage |
|---|---|---|---|---|
| 3500/22-01-02-05 | 3300 XL Proximitor Sensor | 12 mm × 35 mm × 91 mm | 0.15 kg | N/A |
| 3500/15-02-02-00 | Power Supply Module | 22 mm × 129.5 mm × 170 mm | 0.5 kg | 24 V DC |
| 3500/15-03-01-00 | Vibration Monitoring Module | 22 mm × 129.5 mm × 170 mm | 0.3 kg | 24 V DC |
| 3500/15-04-00-00 | High-Speed Relay Module | 22 mm × 129.5 mm × 170 mm | 0.35 kg | 24 V DC |
| 3500/15-02-01-00 | Displacement Sensor Module | 22 mm × 129.5 mm × 170 mm | 0.3 kg | 24 V DC |
