Product Overview
The Bently Nevada 3500/20-01-02-00 Rack Interface Module is an essential component in the 3500 Machinery Protection System, serving as the primary communication link between the monitoring rack and external control or plant monitoring systems. It ensures seamless data transmission for real-time condition monitoring and machinery protection. Designed for industrial-grade reliability, this module supports advanced diagnostics, high-speed data handling, and redundant configurations to minimize downtime and enhance system availability.
Key Features
-
Provides a communication bridge between the 3500 rack and external systems
-
Supports Modbus, Ethernet, and other industrial protocols
-
High-speed data transfer for accurate and timely monitoring
-
Redundant operation support for maximum system reliability
-
Hot-swappable design for maintenance without system interruption
-
Rugged construction for harsh industrial environments
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 3500/20-01-02-00 |
| Module Type | Rack Interface Module |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Compatible Systems | Bently Nevada 3500 Machinery Protection System |
| Communication Protocols | Modbus, Ethernet, and other industrial protocols |
| Data Processing Rate | High-speed data handling and transfer |
| Redundancy Support | Yes, with paired modules |
| Mounting Type | Rack-mounted (3500 rack) |
| Power Supply | Provided by 3500 rack backplane |
| Operating Temperature | 0°C to 65°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 0% to 95% non-condensing |
| Dimensions | 241.3 x 24.4 x 241.8 mm |
| Weight | 0.91 kg |
| Certifications | CE, CSA, ATEX, IECEx |
Industry Applications
-
Turbomachinery protection and diagnostics
-
Oil and gas processing facilities
-
Power generation plants
-
Chemical and petrochemical industries
-
Heavy industrial manufacturing
Frequently Asked Questions (FAQ)
Q1: What is the main role of the 3500/20-01-02-00 module?
It acts as the interface between the 3500 monitoring rack and external plant systems.
Q2: Can it be used with all Bently Nevada 3500 racks?
Yes, it is fully compatible with all standard 3500 racks.
Q3: Does it support redundant configurations?
Yes, it supports redundancy for high availability.
Q4: What communication protocols does it support?
It supports Modbus, Ethernet, and other standard industrial protocols.
Q5: Can it be replaced while the system is in operation?
Yes, it is hot-swappable under supported conditions.
Q6: What are the environmental limits for operation?
It operates between 0°C and 65°C with 0–95% non-condensing humidity.
Q7: Is an external power source required?
No, it draws power from the 3500 rack backplane.
Q8: Is it certified for hazardous locations?
Yes, it has ATEX and IECEx certifications.
Q9: How does it enhance machinery protection?
It ensures rapid, reliable data delivery for early fault detection.
Q10: Can it connect to plant-wide monitoring software?
Yes, it integrates easily with centralized monitoring systems.
